76 EN
RS-232C INTERFACE
81: Title Search under AORIGINALB
E.g.: When searching the 345th title, as indicated by the title number on the top right corner of the index, under AORIGINALB. (A pg. 38)
81: Title Search in APLAY LISTB
E.g.: When searching the 28th play list, as indicated by the play list number on the top right corner of the index, in the APLAY LISTB.
(A pg. 43)
8E: Date Preset
E.g.: When setting the date to January 17 2006.
8F: Clock Preset
E.g.: When setting the time to 12 hrs 34 min and 56 sec.
1st Byte 2nd Byte 3rd Byte 4th Byte
Title Search (ORIGINAL) 30 Hundreds Tens Ones
ASCII codes (30 - 39) 30 3* 3* 3*
E.g. (345) 30 33 34 35
1st Byte 2nd Byte 3rd Byte 4th Byte
Title Search (PLAY LIST) 38 Hundreds Tens Ones
ASCII codes (30 - 39) 38 3* 3* 3*
E.g. (028) 38 30 32 38
1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte
Date Preset Mth (Tens) Mth (Ones) Day (Tens) Day (Ones) Yr (Tens) Yr (Ones)
ASCII code (30 - 39) 3* 3* 3* 3* 3* 3*
E.g. (01.17.2006) 30 31 31 37 30 36
1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte
Clock Preset Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones)
ASCII code (30 - 39) 3* 3* 3* 3* 3* 3*
E.g. (12:34:56) 31 32 33 34 35 36
