JVC TH-A5R Service Manual

TH-A5R
3-7
Item
Parts number Parts name Area
A
Parts list (DVD mechanism)
Q'ty
Description
Block No. MJMM
1 AH61-00746A
BASE-MAIN
1
BLK
2 AH63-00294A
TRAY-DISC
1
D/GRAY
3 AH66-00159A
LEVER-LIFT
1
BLK
4 AH66-00160A
PULLEY-MOTOR
1
5 AH66-00161A
GEAR-PULLEY
1
6 AH66-00162A
GEAR-MIDDLE
1
7 AH66-00163A
GEAR-TRAY
1
8 AH66-00164A
CLAMPER-UPPER
1
UPPER
9 AH66-00165A
CLAMPER-LOWER
1
LOWER
10 AH61-00747A
BRACKET-CHUCK
1
T1.0
11 AH66-00166A
SLIDE-CAM
1
12 AH31-00030A
MOTOR-DC
1
RF-300CA-11440
13 ---------------
PCB-SWITCH
1
26.5 X 21.6
14 AH66-00167A
BELT-PULLEY
1
CR 1.5
15 3409-001119
SWITCH-DETECTOR
1
JDS2200
16 AH59-00130A
DVD DECK
1
CMS-S21MG6
17 6001-001257
SCREW-MACHINE
2
1.7 X 3(W4.5)
18 AJ60-10001A
SCREW-TAP
6
2 X 5(W7)
19 6003-001210
SCREW-TAP
5
2.6 X 6(W12)
20 AH73-00025B
RUBBER-CD
4
BUTYL 15
21 AH61-00958A
BRACKET-GUIDE
1
SECC 1.0T
22 6003-000283
SCREW-TAP
2
3 X 8
23 6003-000276
SCREW-TAP
4
3 X 10
24 AH61-00828A
HOLDER-PCB
1
ABS BLK
