JVC TH-A5R Service Manual

TH-A5R
3-8
AR48 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
BD1 0402-001077 BRIDGE DIODE
A
KBP202G
,
200V
BD2 0402-001258 BRIDGE DIODE
A
GBU606
,
6A
,
600V
BD3 0402-001258 BRIDGE DIODE
A
GBU606
,
6A
,
600V
BD4 0402-001258 BRIDGE DIODE
A
GBU606
,
6A
,
600V
CW1 3711-000190 CONNECTOR
1WALL
,
2P
,
7.92MM
CW2 3711-004848 CONNECTOR
BOX
,
3P
,
7.92MM
,
S
CW3 3711-001098 CONNECTOR
BOX
,
7P
,
2.5MM
,
ST
CW4 3708-001311 CONNECTOR
SCB-1107-00-2
,
7
CW5 3711-004110 CONNECTOR
3WALL
,
12P
,
2MM
,
S
CW6 3711-004110 CONNECTOR
3WALL
,
12P
,
2MM
,
S
CW7 3711-004110 CONNECTOR
3WALL
,
12P
,
2MM
,
S
CW8 3708-001094 CONNECTOR
13P
,
1.25MM
,
ST
C1 2201-000546 C.CAPASITOR
A
4.7NF
,
20%
,
400V
C10 2401-001912 E.CAPACITOR
1UF
,
20%
,
50V
C11 2401-000795 E.CAPACITOR
220UF
,
20%
,
16V
C12 2401-001954 E.CAPACITOR
4.7UF
,
20%
,
50V
C13 2401-001912 E.CAPACITOR
1UF
,
20%
,
50V
C14 2201-000161 C.CAPACITOR
10NF
,
+80-20%
,
50
C15 2201-000161 C.CAPACITOR
10NF
,
+80-20%
,
50
C16 2201-000161 C.CAPACITOR
10NF
,
+80-20%
,
50
C17 2201-000161 C.CAPACITOR
10NF
,
+80-20%
,
50
C18 2401-002258 E.CAPACITOR
A
4700UF
,
20%
,
50V
C19 2401-002258 E.CAPACITOR
A
4700UF
,
20%
,
50V
C2 2201-000546 C.CAPASITOR
A
4.7NF
,
20%
,
400V
C20 2401-003116 E.CAPACITOR
A
4700UF
,
20%
,
35V
C202L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
C202R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
C21 2401-003116 E.CAPACITOR
A
4700UF
,
20%
,
35V
C22 2401-001959 E.CAPACITOR
A
4700UF
,
20%
,
25V
C23 2401-001959 E.CAPACITOR
A
4700UF
,
20%
,
25V
C25 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
C26 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
C27 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
C28 2401-000459 E.CAPACITOR
10UF
,
20%
,
35V
C29 2401-000459 E.CAPACITOR
10UF
,
20%
,
35V
C3 2201-000546 C.CAPASITOR
4.7NF
,
20%
,
400V
C30 2401-001969 E.CAPACITOR
470UF
,
20%
,
25V
C31 2401-001969 E.CAPACITOR
470UF
,
20%
,
25V
C32C 2201-000300 C.CAPACITOR
1NF
,
20%
,
50V
C32FL 2202-000796 C.CAPACITOR
1NF
,
10%
,
50V
C32FR 2202-000796 C.CAPACITOR
1NF
,
10%
,
50V
C32RL 2202-000796 C.CAPACITOR
1NF
,
10%
,
50V
C32RR 2202-000796 C.CAPACITOR
1NF
,
10%
,
50V
C32W 2201-000300 C.CAPACITOR
1NF
,
20%
,
50V
C33C 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
C33FL 2202-000796 C.CAPACITOR
1NF
,
10%
,
50V
C33FR 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
C33RL 2201-000300 C.CAPACITOR
1NF
,
20%
,
50V
C33RR 2201-000300 C.CAPACITOR
1NF
,
20%
,
50V
C33W 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
C34 2401-000385 E.CAPACITOR
10UF
,
20%
,
100V
C35 2401-001361 E.CAPACITOR
470UF
,
16V
,
BP
C37 2401-001975 E.CAPACITOR
47UF
,
20%
,
16V
C39 2401-001538 E.CAPACITOR
47UF
,
20%
,
25V
,
C40C 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C40FL 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C40FR 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C40RL 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C40RR 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C40W 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
C41C 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
C41FL 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
C41FR 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
C41RL 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
C41RR 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
C41W 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C43C 2401-000909 E.CAPACITOR
22UF
,
20%
,
16V
C43FL 2401-000909 E.CAPACITOR
22UF
,
20%
,
16V
C43FR 2401-000909 E.CAPACITOR
22UF
,
20%
,
16V
C43RL 2401-000909 E.CAPACITOR
22UF
,
20%
,
16V
C43RR 2401-000909 E.CAPACITOR
22UF
,
20%
,
16V
C43W 2401-001502 E.CAPACITOR
47UF
,
20%
,
16V
C44C 2203-000704 CHIP CAPACITOR
0.002NF
,
0.25PF
C44FL 2203-000704 CHIP CAPACITOR
0.002NF
,
0.25PF
C44FR 2203-000704 CHIP CAPACITOR
0.002NF
,
0.25PF
C44RL 2203-000704 CHIP CAPACITOR
0.002NF
,
0.25PF
C44RR 2203-000704 CHIP CAPACITOR
0.002NF
,
0.25PF
C44W 2203-000280 CHIP CAPACITOR
10PF
,
0.5PF
,
50V
,
C47C 2301-000375 M.CAPACITOR
100NF
,
10%
,
50V
C47FL 2301-000375 M.CAPACITOR
100NF
,
10%
,
50V
C47FR 2301-000375 M.CAPACITOR
100NF
,
10%
,
50V
C47RL 2301-000375 M.CAPASITOR
100NF
,
10%
,
50V
C47RR 2301-000375 M.CAPASITOR
100NF
,
10%
,
50V
C47W 2301-000375 M.CAPACITOR
100NF
,
10%
,
50V
C5 2201-000546 C.CAPASITOR
4.7NF
,
20%
,
400V
C52 2401-001975 E.CAPACITOR
47UF
,
20%
,
16V
C54 2401-001975 E.CAPACITOR
47UF
,
20%
,
16V
C55 2401-001975 E.CAPACITOR
47UF
,
20%
,
16V
C7 2401-001538 E.CAPACITOR
47UF
,
20%
,
25V
C70FL 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C70FR 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C71C 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C71RL 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C71RR 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C71W 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
C8 2401-000438 E.CAPACITOR
10UF
,
20%
,
25V
C9 2401-001413 E.CAPACITOR
470UF
,
20%
,
35V
D1 0402-000127 DIODE
1N4002
,
100V
D10 0401-001090 DIODE
1SS355
D11 0402-000127 DIODE
1N4002
,
100V
D12 0401-001090 DIODE
1SS355
D13 0401-001090 DIODE
1SS355
D14 0401-001090 DIODE
1SS355
D15 0401-001090 DIODE
1SS355
D16 0401-001090 DIODE
1SS355
D17 0401-001090 DIODE
1SS355
D2 0402-000127 DIODE
1N4002
,
100V
D20 0401-001090 DIODE
1SS355
D201 0401-001090 DIODE
1SS355
D202 0401-001090 DIODE
1SS355
D203 0401-001090 DIODE
1SS355
D204 0401-001090 DIODE
1SS355
D205 0401-001090 DIODE
1SS355
D206 0401-001090 DIODE
1SS355
D207 0401-001090 DIODE
1SS355
D208 0403-001376 ZENER DIODE
UDZ3.6B
,
3.6-3.8
D209 0401-001090 DIODE
1SS355
D21 0401-001090 DIODE
1SS355
D210 0401-001090 DIODE
1SS355
D211 0401-001090 DIODE
1SS355
D212 0401-001090 DIODE
1SS355
D213 0401-001090 DIODE
1SS355
D214 0401-001090 DIODE
1SS355
D215 0401-001090 DIODE
1SS355
D216 0401-001090 DIODE
1SS355
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
e
a
Remarks
A
