JVC TH-A5R Service Manual

TH-A5R
3-9
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
e
a
Remarks
A
D217 0401-001090 DIODE
1SS355
D218 0401-001090 DIODE
1SS355
D22 0402-000309 DIODE
1SR154-400
,
400V
D23 0402-000309 DIODE
1SR154-400
,
400V
D24 0402-000309 DIODE
1SR154-400
,
400V
D28 0401-000900 DIODE
1SS355
D29 0401-001090 DIODE
1SS355
D3 0401-000101 DIODE
1N4148
,
100V
D30 0401-001090 DIODE
1SS355
D31 0401-001090 DIODE
1SS355
D32 0401-001090 DIODE
1SS355
D33 0401-001090 DIODE
1SS355
D34 0401-001090 DIODE
1SS355
D35C 0401-001090 DIODE
1SS355
D35FL 0401-001090 DIODE
1SS355
D35FR 0401-001090 DIODE
1SS355
D35RL 0401-001090 DIODE
1SS355
D35RR 0401-001090 DIODE
1SS355
D35W 0401-001090 DIODE
1SS355
D36C 0401-001090 DIODE
1SS355
D36FL 0401-001090 DIODE
1SS355
D36FR 0401-001090 DIODE
1SS355
D36RL 0401-001090 DIODE
1SS355
D36RR 0401-001090 DIODE
1SS355
D36W 0401-001090 DIODE
1SS355
D37C 0401-001090 DIODE
1SS355
D37FL 0401-001090 DIODE
1SS355
D37FR 0401-001090 DIODE
1SS355
D37RL 0401-001090 DIODE
1SS355
D37RR 0401-001090 DIODE
1SS355
D37W 0401-001090 DIODE
1SS355
D38C 0401-001090 DIODE
1SS355
D38FL 0401-001090 DIODE
1SS355
D38FR 0401-001090 DIODE
1SS355
D38RL 0401-001090 DIODE
1SS355
D38RR 0401-001090 DIODE
1SS355
D38W 0401-001090 DIODE
1SS355
D39C 0402-000309 DIODE
1SR154-400
,
400V
D39FL 0402-000309 DIODE
1SR154-400
,
400V
D39FR 0402-000309 DIODE
1SR154-400
,
400V
D39RL 0402-000309 DIODE
1SR154-400
,
400V
D39RR 0402-000309 DIODE
1SR154-400
,
400V
D39W 0402-001484 DIODE
S2B
,
100V
,
1.5A
D4 0402-000127 DIODE
1N4002
,
100V
D40C 0402-000309 DIODE
1SR154-400
,
400V
D40FL 0402-000309 DIODE
1SR154-400
,
400V
D40FR 0402-000309 DIODE
1SR154-400
,
400V
D40RL 0402-000309 DIODE
1SR154-400
,
400V
D40RR 0402-000309 DIODE
1SR154-400
,
400V
D40W 0402-000309 DIODE
1SR154-400
,
400V
D41C 0402-000309 DIODE
1SR154-400
,
400V
D41FL 0402-000309 DIODE
1SR154-400
,
400V
D41FR 0402-000309 DIODE
1SR154-400
,
400V
D41RL 0402-000309 DIODE
1SR154-400
,
400V
D41RR 0402-000309 DIODE
1SR154-400
,
400V
D41W 0402-000309 DIODE
1SR154-400
,
400V
D42C 0402-000309 DIODE
1SR154-400
,
400V
D42FL 0402-000309 DIODE
1SR154-400
,
400V
D42FR 0402-000309 DIODE
1SR154-400
,
400V
D42RL 0402-000309 DIODE
1SR154-400
,
400V
D42RR 0402-000309 DIODE
1SR154-400
,
400V
D42W 0402-001484 DIODE
S2B
,
100V
,
1.5A
D5 2003-000603 OMF RESISTOR
270OHM
,
5%
,
1W
D51 0401-001090 DIODE
1SS355
D52 0401-001090 DIODE
1SS355
D53 0401-001090 DIODE
1SS355
D54 0401-001090 DIODE
1SS355
D55 0401-001090 DIODE
1SS355
D6 0402-000127 DIODE
1N4002
,
100V
D65 0401-001090 DIODE
1SS355
D7 2003-000603 OMF RESISTOR
270OHM
,
5%
,
1W
D8 0402-000127 DIODE
1N4002
,
100V
D9 0401-001090 DIODE
1SS355
FU1 3601-000216 FUSE
A
250V
,
2.5A
,
TIME-
FU3 3601-000319 FUSE
A
80MA
(
15.5MM
)
IC1 1203-000276 IC
KA7805-AB
IC2 1201-000163 IC
4560
,
SOPP
,
150MI
IC3 1203-000242 IC
7812
,
TO-220
IC4 1203-000110 IC
KA7912-AB
IC5 1201-000163 IC
4560
,
SOPP
,
150MI
IC6 1201-000163 IC
4560
,
SOPP
,
150MI
IC7 1201-000163 IC
4560
,
SOPP
,
150MI
IC8 1203-000242 IC
7812
,
TO-220
JW100 2007-000033 CHIP RESISTOR
0OHM
,
5%
,
1/8W
JW102 2007-000033 CHIP RESISTOR
0OHM
,
5%
,
1/8W
JW104 2007-000033 CHIP RESISTOR
0OHM
,
5%
,
1/8W
JW106 2007-000033 CHIP RESISTOR
0OHM
,
5%
,
1/8W
J1 3716-001173 TERMINAL BLOCK
SOLDERP
,
12.5MM
J2 3716-001132 TERMINAL BLOCK
P40420421P-RED
,
J3 3722-001727 PIN JACK
2P.3PI
,
NI-P
,
BLK
L1 AH27-10001F COIL
A
27UH
L2 AH27-10001F COIL
A
27UH
L3C AH27-90001A SPRING COIL
2.2UH
,
SPRING
L3FL AH27-90001A SPRING COIL
2.2UH
,
SPRING
L3FR AH27-90001A SPRING COIL
2.2UH
,
SPRING
L3RL AH27-90001A SPRING COIL
2.2UH
,
SPRING
L3RR AH27-90001A SPRING COIL
2.2UH
,
SPRING
L3W AH27-90001A SPRING COIL
2.2UH
,
SPRING
MC601 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MC602 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MC603 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MC604 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MC605 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MC606 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
MR18 2007-000106 CHIP RESISTOR
220KOHM
,
5%
,
1/16
MR19 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
PBD1 0402-001258 BRIDGE DIODE
A
GBU606
,
6A
,
600V
PBD2 0402-001408 BRIDGE DIODE
A
KBP005G
,
50V
PC1 2401-000230 E.CAPACITOR
100UF
,
20%
,
100V
PC10 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC11 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PC12 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PC13 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC14 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PC15 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PC16 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC17 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PC18 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC19 2201-000546 C.CAPASITOR
4.7NF
,
20%
,
400V
PC2 2401-000357 E.CAPACITOR
100UF
,
0.2
,
50V
PC20 2201-000546 C.CAPASITOR
4.7NF
,
20%
,
400V
PC3 2401-001879 E.CAPACITOR
A
10000UF
,
20%
,
16V
PC4 2401-001879 E.CAPACITOR
A
10000UF
,
20%
,
16V
PC5 2401-001052 E.CAPACITOR
3300UF
,
20%
,
25V
PC6 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC7 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
