JVC TH-A5R Service Manual

TH-A5R
3-10
PC8 2401-000475 E.CAPACITOR
10UF
,
20%
,
50V
PC9 2401-001895 E.CAPACITOR
100UF
,
20%
,
16V
PD1 0402-000127 DIODE
1N4002
,
100V
PD10 0404-000156 SCHOTTKY DIODE
RB441Q
,
10V
PD2 0401-000101 DIODE
1N4148
,
100V
PD3 0401-000101 DIODE
1N4148
,
100V
PD4 0401-000101 DIODE
1N4148
,
100V
PD5 0401-000101 DIODE
1N4148
,
100V
PD7 0401-000101 DIODE
1N4148
,
100V
PD8 0401-000101 DIODE
1N4148
,
100V
PD9 0401-000101 DIODE
1N4148
,
100V
P
Q
1 1203-001006 IC
78R05
,
T0-220F
,
4
P
Q
2 1203-001006 IC
78R05
,
T0-220F
,
4
P
Q
3 0502-000303 TRANSISTOR
KSD882
,
NPN
,
1W
P
Q
4 1203-001586 IC
278R33
,,
4P
P
Q
5 1203-001697 IC
78R08 T0-220 4P
P
Q
6 1203-001006 IC
78R05
,
T0-220F
,
4
P
Q
7 1203-002296 IC
BA3254FP-E2
PR1 2003-000701 OMF RESISTOR
470OHM
,
5%
,
2W
PR10 2003-000629 OMF RESISTOR
3.3OHM
,
5%
,
2W
PR11 2003-000629 OMF RESISTOR
3.3OHM
,
5%
,
2W
PR2 2007-000091 CHIP RESISTOR
12KOHM
,
5%
,
1/16W
PR21 2007-000091 CHIP RESISTOR
12KOHM
,
5%
,
1/16W
PR3 2007-000309 CHIP RESISTOR
10OHM
,
5%
,
1/16W
PR4 2003-000471 OMF RESISTOR
10OHM
,
5%
,
2W
PR5 2007-000309 CHIP RESISTOR
10OHM
,
5%
,
1/16W
PR6 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
PR7 2007-000129 CHIP RESISTOR
27KOHM
,
5%
,
1/16W
PR8 2007-000092 CHIP RESISTOR
15KOHM
,
5%
,
1/16W
PR9 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
PT1 AH26-00143C POWER TRANS
A
HT-DL1006
,
276V
PW1 3711-000963 CONNECTOR
BOX
,
4P
,
2.5MM
,
ST
PW2 3711-003111 CONNECTOR
BOX
,
6P
,
2.5MM
,
ST
PW3 3711-004109 CONNECTOR
3WALL
,
14P
,
2MM
,
S
PW5 3708-001311 CONNECTOR
SCB-1107-00-2
,
7
PZD1 0403-000564 ZENER DIODE
TZP16A
,
16V
,
1W
,
PZD2 0403-000564 ZENER DIODE
TZP16A
,
16V
,
1W
,
Q
1 0504-000118 TRANSISTOR
KSR1003
,
NPN
,
300
Q
10 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
11 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
12 0504-001003 TRANSISTOR
KSR2003TA
Q
13 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
14 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
15 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
16 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
17C 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
17FL 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
17FR 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
17RL 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
17RR 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
17W 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18C 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18FL 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18FR 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18RL 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18RR 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
18W 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
19C 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
19FL 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
19FR 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
19RL 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
19RR 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
19W 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
2 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
20C 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
20FL 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
20FR 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
20RL 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
20RR 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
20W 0501-000303 TRANSISTOR
KSA733
,
PNP
Q
21C 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
21FL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
21FR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
21RL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
21RR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
21W 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
22C 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
22FL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
22FR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
22RL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
22RR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
22W 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23C 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23FL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23FR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23RL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23RR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
23W 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24C 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24FL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24FR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24RL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24RR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
24W 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25C 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25FL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25FR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25RL 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25RR 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
25W 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
26C 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
26FL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
26FR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
26RL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
26RR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
26W 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27C 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27FL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27FR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27RL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27RR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
27W 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28C 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28FL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28FR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28RL 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28RR 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
28W 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
29C 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
29FL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
29FR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
29RL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
29RR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
29W 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
3 0501-000010 TRANSISTOR
KSC1008
,
NPN
Q
30C 0502-001048 TRANSISTOR
KSD1691
,
NPN
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
e
a
Remarks
A
