JVC TH-A5R Service Manual

TH-A5R
3-11
Q
30FL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
30FR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
30RL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
30RR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
30W 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31C 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31FL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31FR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31RL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31RR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
31W 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
32C 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
32FL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
32FR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
32RL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
32RR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
32W 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33C 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33FL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33FR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33RL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33RR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
33W 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34C 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34FL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34FR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34RL 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34RR 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
34W 0502-001210 TRANSISTOR
KSB1151
,
PNP
Q
35C 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
35FL 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
35FR 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
35RL 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
35RR 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
35W 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
36C 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
36FL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
36FR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
36RL 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
36RR 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
36W 0502-001048 TRANSISTOR
KSD1691
,
NPN
Q
37 0504-000156 TRANSISTOR
KSR2103
,
PNP
,
200
Q
38 0504-000156 TRANSISTOR
KSR2103
,
PNP
,
200
Q
39 0504-000156 TRANSISTOR
KSR2103
,
PNP
,
200
Q
4 0501-000294 TRANSISTOR
KSA708-Y
,
PNP
Q
40 0502-000299 TRANSISTOR
KSD73-Y
,
NPN
Q
5 0501-000398 TRANSISTOR
KSC945
,
NPN
Q
6 0501-000610 TRANSISTOR
KSA928A-Y
,
PNP
Q
7 0501-000314 TRANSISTOR
KSA812
,
PNP
Q
8 0501-000341 TRANSISTOR
KSC1623-L
,
NPN
Q
9 0501-000010 TRANSISTOR
KSC1008
,
NPN
RE1 3501-001214 RELAY
A
12V
,
0.45W1FORMA
RE3 3501-001008 RELAY
A
G2R-1 DC12
RE5 3501-001197 RELAY
OSA-SS-212DM3
RE6 3501-001197 RELAY
OSA-SS-212DM3
RE7 3501-001197 RELAY
OSA-SS-212DM3
R10 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1/16
R100 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R101 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R102 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
R103 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R104 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R105 2007-000077 CHIP RESISTOR
470OHM
,
5%
,
1/16W
R106 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R107 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R108 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
R109 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R11 2001-000864 CARBON RESISTOR
56KOHM
,
5%
,
1/8W
R110 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R111 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R112 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R113 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
R114 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R115 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R116 2007-000077 CHIP RESISTOR
470OHM
,
5%
,
1/16W
R117 2007-001179 CHIP RESISTOR
8.2KOHM
,
5%
,
1/16
R118 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R119 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
R12 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
R120 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R121 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R122 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R123 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R124 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
R125 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R126 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R127 2007-000077 CHIP RESISTOR
470OHM
,
5%
,
1/16W
R128 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R129 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R13 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1/16
R130 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
R131 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R132 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R134 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
R135 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
R136 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1/16
R137 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
R137C 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
R14 2007-000091 CHIP RESISTOR
12KOHM
,
5%
,
1/16W
R142 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
R143 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
R144L 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
R144R 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
R145L 2007-000091 CHIP RESISTOR
12KOHM
,
5%
,
1/16W
R145R 2007-000091 CHIP RESISTOR
12KOHM
,
5%
,
1/16W
R146 2001-000850 CARBON RESISTOR
560KOHM
,
5%
,
1/8W
R15 2001-000702 CARBON RESISTOR
39KOHM
,
5%
,
1/8W
R16 2007-000081 CHIP RESISTOR
2.7KOHM
,
5%
,
1/16
R17 2007-000098 CHIP RESISTOR
56KOHM
,
5%
,
1/16W
R18 2007-000098 CHIP RESISTOR
56KOHM
,
5%
,
1/16W
R19 2007-000134 CHIP RESISTOR
33KOHM
,
5%
,
1/16W
R2 2001-000890 CARBON RESISTOR
6.8KOHM
,
5%
,
1/8W
R20 2007-000134 CHIP RESISTOR
33KOHM
,
5%
,
1/16W
R200L 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R200R 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
R201L 2007-000134 CHIP RESISTOR
33KOHM
,
5%
,
1/16W
R201R 2007-000134 CHIP RESISTOR
33KOHM
,
5%
,
1/16W
R21 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
R22 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
R25 2003-000767 OMF RESISTOR
680OHM
,
5%
,
2W
R3 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R30 2003-000765 OMF RESISTOR
680OHM
,
5%
,
1W
R31 2001-000110 CARBON RESISTOR
10OHM
,
5%
,
1/4W
R32C 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R32FL 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
R32FR 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
e
a
Remarks
A
