JVC TH-A5R Service Manual

TH-A5R
3-15
CC11 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
CC12 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
CC13 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
CC14 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
CC15 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
CC16 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
CC17 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
CC18 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
CC19 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
CC20 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
CC21 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
CC22 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
CC23 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
CC24 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
CC27 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
CIC11 1201-000163 IC
4560
,
SOPP
,
150MI
CIC12 1204-001465 IC
TDA7440D
,
28
CIC13 1201-000163 IC
4560
,
SOPP
,
150MI
CR11 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
CR12 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
CR13 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
CR14 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
CR15 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
CR16 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
CR17 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
CR18 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
CR19 2007-000120 CHIP RESISTOR
680OHM
,
5%
,
1/16W
CR21 2007-007361 CHIP RESISTOR
82OHM
,
5%
,
1/2W
CR30 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
CR31 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
CZD11 0403-001409 ZENER DIODE
RLZ9.1B.500MW
DB1 3301-000353 BEAD
BLM21A121SP
DB12 3301-000353 BEAD
BLM21A121SP
DB13 3301-000353 BEAD
BLM21A121SP
DB14 3301-000353 BEAD
BLM21A121SP
DB15 3301-000353 BEAD
BLM21A121SP
DB16 3301-000353 BEAD
BLM21A121SP
DB18 3301-000353 BEAD
BLM21A121SP
DB19 3301-000353 BEAD
BLM21A121SP
DB20 2007-000077 CHIP RESISTOR
470OHM
,
5%
,
1/16W
DB22 3301-000353 BEAD
BLM21A121SP
DB23 3301-000353 BEAD
BLM21A121SP
DB24 3301-000353 BEAD
BLM21A121SP
DB25 3301-000353 BEAD
BLM21A121SP
DB26 3301-000353 BEAD
BLM21A121SP
DB27 3301-000353 BEAD
BLM21A121SP
DB28 3301-000353 BEAD
BLM21A121SP
DB29 3301-000353 BEAD
BLM21A121SP
DB30 3301-000353 BEAD
BLM21A121SP
DC11 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC12 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
DC13 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC133 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC14 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC15 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC16 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
DC17 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC18 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC19 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC20 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC21 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC22 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC23 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC24 2401-000243 E.CAPACITOR
100UF
,
20%
,
10V
DC25 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
DC26 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC27 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC28 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
DC29 2203-000257 CHIP CAPACITOR
10NF
,
10%
,
50V
DC30 2203-001656 CHIP CAPACITOR
0.47NF
,
5%
,
50V
,
N
DC31 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC32 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC33 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC34 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC36 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC37 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC38 2203-000257 CHIP CAPACITOR
10NF
,
10%
,
50V
DC39 2203-000491 CHIP CAPACITOR
2.2NF
,
10%
,
50V
DC40 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC41 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC42 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
DC43 2203-000257 CHIP CAPACITOR
10NF
,
10%
,
50V
DC44 2203-000257 CHIP CAPACITOR
10NF
,
10%
,
50V
DC45 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
DC46 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC48 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC49 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC51 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC71 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC72 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC73 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DC74 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC86 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC87 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC88 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
DC89 2203-000257 CHIP CAPACITOR
10NF
,
10%
,
50V
DC91 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
DD11 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
DIC11 1204-001841 IC
CS493292-CL
,
PLC
DIC12 0801-002564 IC
74VHCT244A
,
BUFF
DIC13 0802-001007 IC
74LCX244
,
BUFFER
DIC14 1001-001170 IC
CS8415A-CZ
DIC15 1204-001842 IC
CS4228A-KS
,
28P
DIC16 0801-002639 IC
74VHC574
,
20P
DIC17 0801-002639 IC
74VHC574
,
20P
DIC21 1103-001181 IC
27L010
,
32P
D
Q
13 0501-000314 TRANSISTOR
KSA812
,
PNP
DR12 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR13 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR14 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR15 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR16 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
DR17 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
DR18 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR19 2007-000134 CHIP RESISTOR
33KOHM
,
5%
,
1/16W
DR21 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
DR22 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR23 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR24 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR25 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR26 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR27 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR28 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR29 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR30 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR32 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
Item
Parts number Parts name Ar
e
a
Electrical parts list (DSP board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
