JVC TH-A5R Service Manual

TH-A5R
3-16
DR33 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR34 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
DR36 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR37 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
DR38 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
DR39 2007-000124 CHIP RESISTOR
2.2KOHM
,
5%
,
1/16
DR40 2007-000309 CHIP RESISTOR
10OHM
,
5%
,
1/16W
DR41 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
DR42 2007-000113 CHIP RESISTOR
33OHM
,
5%
,
1/16W
DR43 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR44 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR45 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR46 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR47 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR501 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
DR51 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
DR52 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
DR61 2007-001167 CHIP RESISTOR
75OHM
,
5%
,
1/16W
DR62 2007-002425 CHIP RESISTOR
1OHM
,
5%
,
1/16W
DR71 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
DW10 3710-001422 CONNECTOR
12P
,
2MM
,
ANGLE
DW11 3711-000426 CONNECTOR
3WALL
,
15P
,
2MM
,
S
DW12 3711-000426 CONNECTOR
3WALL
,
15P
,
2MM
,
S
DW13 3710-001422 CONNECTOR
12P
,
2MM
,
ANGLE
DW14 3710-001422 CONNECTOR
12P
,
2MM
,
ANGLE
DW15 3710-001421 CONNECTOR
14P
,
2MM
,
ANGLE
DW20 3708-000178 CONNECTOR
16P
,
1.25MM
,
ANGL
DW22 3708-001094 CONNECTOR
13P
,
1.25MM
,
STT
DW23 3710-001422 CONNECTOR
12P
,
2MM
,
ANGLE
DW31 3710-001734 CONNECTOR
15P
,
2MM
,
STT
DW32 3710-001734 CONNECTOR
15P
,
2MM
,
STT
DX11 2804-001446 OSCILLATOR
12.288MHZ
,
25PPM
FC1 2401-001889 E.CAPACITOR
100NF
,
20%
,
50V
FC10 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC11 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC12 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC13 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC14L 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC14R 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC15 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
FC16 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC17L 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC17R 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC18 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC19L 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC19R 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC2 2401-001889 E.CAPACITOR
100NF
,
20%
,
50V
FC20L 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC20R 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC23 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC24 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC25 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC26 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
FC27 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
FC28 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
FC3 2401-001324 E.CAPACITOR
470NF
,
20%
,
50V
FC41 2203-000888 CHIP CAPACITOR
4.7NF
,
10%
,
50V
FC42 2203-000604 CHIP CAPACITOR
22NF
,
10%
,
25V
FC43L 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
FC43R 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
FC44L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC44R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC45L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC45R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC46L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC46R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC47L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC47R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC48L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC48R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
FC49L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC49R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC50L 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
FC50R 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
FC51L 2203-000491 CHIP CAPACITOR
2.2NF
,
10%
,
50V
FC51R 2203-000491 CHIP CAPACITOR
2.2NF
,
10%
,
50V
FC52L 2203-000236 CHIP CAPACITOR
100PF
,
5%
,
50V
,
NP
FC52R 2203-000236 CHIP CAPACITOR
100PF
,
5%
,
50V
,
NP
FC53L 2203-000236 CHIP CAPACITOR
100PF
,
5%
,
50V
,
NP
FC53R 2203-000236 CHIP CAPACITOR
100PF
,
5%
,
50V
,
NP
FC55L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC55R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC56 2203-001034 CHIP CAPACITOR
5.6NF
,
10%
,
50V
FC57 2203-001034 CHIP CAPACITOR
5.6NF
,
10%
,
50V
FC58L 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
FC58R 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
FC6 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC60L 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
FC60R 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
FC7 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC71 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC72 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC73 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC73L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC73R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
FC74 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
FC8 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC9 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
FC99 2401-000588 E.CAPACITOR
1UF
,
20%
,
50V
FIC1 AC14-12001G IC
KA78L05Z-TA
,
3P
FIC11 1201-000163 IC
4560
,
SOPP
,
150MI
FIC12 1204-001465 IC
TDA7440D
,
28
FIC2 1201-000163 IC
4560
,
SOPP
,
150MI
FIC4 1201-000163 IC
4560
,
SOPP
,
150MI
FIC5 1201-000163 IC
4560
,
SOPP
,
150MI
FIC6 1201-000163 IC
4560
,
SOPP
,
150MI
FR1 2007-000644 CHIP RESISTOR
270OHM
,
5%
,
1/2W
FR10 2007-000101 CHIP RESISTOR
82KOHM
,
5%
,
1/16W
FR11 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
FR12L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR12R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR13L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR13R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR14L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR14R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR15L 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
FR15R 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
FR16L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR16R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR17L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR17R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR18L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR18R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR19L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR19R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR2 2007-007147 CHIP RESISTOR
680OHM
,
5%
,
1/4W
Item
Parts number Parts name Ar
e
a
Electrical parts list (DSP board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
