JVC TH-A5R Service Manual

TH-A5R
3-17
FR20L 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
FR20R 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
FR21L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR21R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
FR22L 2007-000402 CHIP RESISTOR
150OHM
,
5%
,
1/16W
FR22R 2007-000402 CHIP RESISTOR
150OHM
,
5%
,
1/16W
FR23L 2007-000402 CHIP RESISTOR
150OHM
,
5%
,
1/16W
FR23R 2007-000402 CHIP RESISTOR
150OHM
,
5%
,
1/16W
FR24L 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR24R 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR25L 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR25R 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR26L 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR26R 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
FR28L 2007-000129 CHIP RESISTOR
27KOHM
,
5%
,
1/16W
FR28R 2007-000129 CHIP RESISTOR
27KOHM
,
5%
,
1/16W
FR31 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
FR32 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
FR34L 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1/16
FR34R 2007-000102 CHIP RESISTOR
100KOHM
,
5%
,
1/16
FR35L 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
FR35R 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
FR36L 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
FR36R 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
FR4 2007-000101 CHIP RESISTOR
82KOHM
,
5%
,
1/16W
FR5 2007-000098 CHIP RESISTOR
56KOHM
,
5%
,
1/16W
FR51L 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
FR51R 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
FR52L 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
FR52R 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
FR53L 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
FR53R 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
FR54L 2007-000123 CHIP RESISTOR
1.5KOHM
,
5%
,
1/16
FR54R 2007-000123 CHIP RESISTOR
1.5KOHM
,
5%
,
1/16
FR6 2007-000098 CHIP RESISTOR
56KOHM
,
5%
,
1/16W
FR7 2007-000129 CHIP RESISTOR
27KOHM
,
5%
,
1/16W
FZD1 0403-001387 ZENER DIODE
UDZS5.1B
,
4.89-5
NC11 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
NW11 3711-000820 CONNECTOR
BOX
,
2P
,
2.5MM
,
ST
ODR11 2007-000070 CHIP RESISTOR
0OHM
,
5%
,
1/16W
ODR20 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
ODR31 2007-000090 CHIP RESISTOR
10KOHM
,
5%
,
1/16W
RC11 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
RC12 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
RC13 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
RC14 2401-000650 E.CAPACITOR
2.2UF
,
20%
,
50V
RC15 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
RC16 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
RC17 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
RC18 2401-001502 E CAPACITOR
47UF
,
20%
,
16V
RC19 2401-001889 E.CAPACITOR
100NF
,
20%
,
50V
RC20 2401-001889 E.CAPACITOR
100NF
,
20%
,
50V
RC31L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
RC31R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
RC32L 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
RC32R 2203-000440 CHIP CAPACITOR
1NF
,
10%
,
50V
RC33L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC33R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC34L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC34R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC35L 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC35R 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
RC36L 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
RC36R 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
RC39L 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
RC39R 2203-000531 CHIP CAPACITOR
2.7NF
,
10%
,
50V
RC51L 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
RC51R 2203-001554 CHIP CAPACITOR
1.8NF
,
10%
,
50V
RIC11 1201-000163 IC
4560
,
SOPP
,
150MI
RIC12 1204-001465 IC
TDA7440D
,
28
RIC13 1201-000163 IC
4560
,
SOPP
,
150MI
RR11L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR11R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR12L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR12R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR13L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR13R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR14L 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR14R 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
RR15L 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
RR15R 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
RR16L 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
RR16R 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
RR17L 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
RR17R 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
RR18L 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
RR18R 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
RR19L 2007-000120 CHIP RESISTOR
680OHM
,
5%
,
1/16W
RR19R 2007-000120 CHIP RESISTOR
680OHM
,
5%
,
1/16W
RR20 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
RR21 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
RR25L 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
RR25R 2007-000078 CHIP RESISTOR
1KOHM
,
5%
,
1/16W
SC11 2401-000407 E.CAPACITOR
10UF
,
20%
,
16V
SC12 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
SC13 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
SC14 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
SC18 2203-005221 CHIP CAPACITOR
15NF
,
10%
,
50V
,
SC19 2203-001389 CHIP CAPACITOR
12NF
,
10%
,
50V
SC20 2203-001211 CHIP CAPACITOR
8.2NF
,
10%
,
50V
SC22 2203-000783 CHIP CAPACITOR
0.33NF
,
5%
,
50V
,
N
SC23 2203-000604 CHIP CAPACITOR
22NF
,
10%
,
25V
SR11 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
SR12 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
SR13 2007-000094 CHIP RESISTOR
22KOHM
,
5%
,
1/16W
SR14 2007-000082 CHIP RESISTOR
3.3KOHM
,
5%
,
1/16
SR15 2007-000086 CHIP RESISTOR
5.6KOHM
,
5%
,
1/16
SR16 2007-000075 CHIP RESISTOR
220OHM
,
5%
,
1/16W
SR17 2007-000097 CHIP RESISTOR
47KOHM
,
5%
,
1/16W
SR18 2007-000084 CHIP RESISTOR
4.7KOHM
,
5%
,
1/16
SR19 2007-000074 CHIP RESISTOR
100OHM
,
5%
,
1/16W
UC1 2409-000123 C-EDL
47000UF
,
4UA
,
5.5
UC101 2401-000243 E.CAPACITOR
100UF
,
20%
,
10V
UC2 2401-001238 E.CAPACITOR
4.7UF
,
20%
,
25V
UC3 2401-000752 E.CAPACITOR
220NF
,
20%
,
50V
UC4 2401-000243 E.CAPACITOR
100UF
,
20%
,
10V
UC46 2203-000236 CHIP CAPACITOR
100PF
,
5%
,
50V
,
NP
UC5 2203-000062 CHIP CAPACITOR
47NF
,
+80-20%
,
50
UC6 2203-005005 CHIP CAPACITOR
100NF
,
10%
,
16C
UC82 2203-000604 CHIP CAPACITOR
22NF
,
10%
,
25V
,
UD10 0402-000309 DIODE
1SR154-400
,
400V
UD4 0401-001090 DIODE
1SS355
UD5 0401-001090 DIODE
1SS355
UD6 0402-000309 DIODE
1SR154-400
,
400V
UD7 0401-001090 DIODE
1SS355
UD8 0401-001090 DIODE
1SS355
Item
Parts number Parts name Ar
e
a
Electrical parts list (DSP board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
