SPECIFICATION
Center unit (XV-THC30/XV-THC20)
*1: This value is measured at System cord CONNECTOR for reference.
*2: Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz)
Subwoofer (SP-PWC30)
Subwoofer (SP-PWC20)
Audio section Total Harmonic Distortion *1 0.02%
Digital input *2 DIGITAL IN (DBS) (OPTICAL) : -21 dBm to -15 dBm (660 nm ± 30 nm)
Video section Video System NTSC
Horizontal Resolution 500 lines
Signal-to-Noise Ratio 64 dB
Video output level Composite : 1.0 V(p-p)/75
Ω
S-video-Y : 1.0 V(p-p)/75 Ω
S-video-C : 0.286 V(p-p)/75 Ω
Component-Y : 1.0 V(p-p)/75 Ω
Component-PB/PR : 0.7 V(p-p)/75 Ω
Video input sensitivity/Impedance (VCR IN) Composite : 1.0 V(p-p)/75 Ω
S-video-Y : 1.0 V(p-p)/75 Ω
S-video-C : 0.286 V(p-p)/75 Ω
USB storage USB specification Compatible with the USB 2.0 Full-Speed
Compatible device Mass Storage Class
Compatible file system FAT16, FAT32
Bus power supply Max. 500 mA
Tuner section Tuning Range FM : 87.5 MHz to 108.0 MHz
AM : 530 kHz to 1 710 kHz
General Power Requirements AC 120 V , 60 Hz
Power Consumption 25 W (at operation)
0.6 W (in standby mode)
Dimensions (W
× H × D) 400 mm × 85 mm × 316 mm (15-3/4 inches × 3-3/8 inches × 12-1/2 inches)
Mass 3.8 kg (8.4 lbs)
Amplifier section Front/Center/Surround 167 W per channel, RMS at 3
Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer 167 W, RMS at 3
Ω at 100 Hz, with 10 % total harmonic distortion.
Speaker section Speaker unit 16 cm (6-5/16 inches) Bass-reflex
Power Handling Capacity 170 W
Impedance 3
Ω
Frequency Range 30 Hz to 200 Hz
Sound Pressure Level 73 dB/W·m
General Power Requirements AC 120 V , 60 Hz
Power Consumption 160 W (at operation)
0 W (in standby mode)
Dimensions (W
× H × D) 170 mm × 411 mm × 458 mm (6-3/4 inches × 16-3/16 inches × 18-1/16 inches)
Mass 11.5 kg (25.4 lbs)
Amplifier section Front/Center/Surround 135 W per channel, RMS at 4
Ω at 1 kHz, with 10 % total harmonic distortion.
Subwoofer 135 W, RMS at 4
Ω at 100 Hz, with 10 % total harmonic distortion.
Speaker section Speaker unit 16 cm (6-5/16 inches) Bass-reflex
Power Handling Capacity 140 W
Impedance 4
Ω
Frequency Range 30 Hz to 200 Hz
Sound Pressure Level 74 dB/W·m
General Power Requirements AC 120 V , 60 Hz
Power Consumption 135 W (at operation)
0 W (in standby mode)
Dimensions (W
× H × D) 170 mm × 411 mm × 458 mm (6-3/4 inches × 16-3/16 inches × 18-1/16 inches)
Mass 11.5 kg (25.4 lbs)
