JVC TH-C30J - Page 49

3-15
Mother board
Block No. [0][3]
R2620 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2621 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R2922 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6001 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6107 NRSA63J-390X MG RESISTOR 39 Ω 1/16W J
R6207 NRSA63J-390X MG RESISTOR 39
Ω 1/16W J
CN101 QGB2501J1-06 CONNECTOR B-B (1-6)
CN102 QGF1036F2-25 CONNECTOR FFC/FPC (1-25)
CN414 QGB2501K2-06 CONNECTOR B-B (1-6)
CN415 QGB2501K2-06 CONNECTOR B-B (1-6)
CN501 QGF1036F2-17 CONNECTOR FFC/FPC (1-17)
CN502 QGF1205F2-07 CONNECTOR FFC/FPC (1-7)
CN511 WJP0079-002A-E E-SH C WIRE C-B
DI501 QLF0168-001 FL TUBE
EP511 QNZ0870-001 EARTH PLATE
J1101 QNN0598-001 PIN JACK
J1103 QND0118-001 DIN CONNECTOR
J6001 QNS0231-001 JACK
J6101 QNZ0851-001 USB CONNECTOR
JS541 QSW1059-001 JOG VOLUME
K501 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K502 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K503 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K504 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
K6101 NQR0502-001X FERRITE BEADS
K6102 NQR0022-002X FERRITE BEADS
K6103 NQR0022-002X FERRITE BEADS
K6104 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
S521 QSW1120-001Z PUSH SW I.M
S531 QSW0522-002Z PUSH SW I.M
S532 QSW0522-002Z PUSH SW I.M
S533 QSW0522-002Z PUSH SW I.M
S534 QSW0522-002Z PUSH SW I.M
S535 QSW0522-002Z PUSH SW I.M
S536 QSW0522-002Z PUSH SW I.M
S537 QSW0522-002Z PUSH SW I.M
S538 QSW0522-002Z PUSH SW I.M
S539 QSW0522-002Z PUSH SW I.M
S540 QSW0522-002Z PUSH SW I.M
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC C30J,C30C
 IC201 STK413-400 IC C20J,C20C
 IC202 STK413-430 IC C30J,C30C
 IC202 STK413-400 IC C20J,C20C
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
Q152 KTC2026/Y/ TRANSISTOR
Q501 RT1P441C-X DIGI TRANSISTOR
Q502 2SC3928A/QR/-X TRANSISTOR
Q503 2SC3928A/QR/-X TRANSISTOR
Q504 2SA1530A/QR/-X TRANSISTOR
Q505 RT1N44HC-X DIGI TRANSISTOR
Q517 RT1N431C-X TRANSISTOR
Q523 2SC3928A/QR/-X TRANSISTOR
Q524 2SA1530A/QR/-X TRANSISTOR
Q525 2SC3928A/QR/-X TRANSISTOR
Q542 RT1N136C-X DIGI TRANSISTOR
Q603 2SC3928A/QR/-X TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 2SA1530A/QR/-X TRANSISTOR
Q2201 2SA1530A/QR/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
Q2301 2SA1530A/QR/-X TRANSISTOR
Q2401 2SA1530A/QR/-X TRANSISTOR
Q2501 2SA1530A/QR/-X TRANSISTOR
Q2601 2SA1530A/QR/-X TRANSISTOR
Q2701 2SC3928A/QR/-X TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 RT1N141C-X DIGI TRANSISTOR
Q2707 KTA1267/YG/-T TRANSISTOR
Q2708 KTC3199/GL/-T TRANSISTOR
Q3702 RT1P141C-X DIGI TRANSISTOR
Q3703 RT1N241C-X DIGITAL TR
Q3704 KTC2026/Y/ TRANSISTOR
D101 1SS133-T2 SI DIODE IM
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D154 1SS133-T2 SI DIODE IM
D163 1SS133-T2 SI DIODE IM
D164 MTZJ6.2B-T2 Z DIODE
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 SI DIODE IM
D504 1SS133-T2 SI DIODE IM
D505 UDZS5.1B-X Z DIODE
D506 1SS133-T2 SI DIODE IM
D507 1SS355-X DIODE C.M
D510 1SS133-T2 SI DIODE IM
D514 1SS133-T2 SI DIODE IM
D515 1SS133-T2 SI DIODE IM
D516 MTZJ30C-T2 Z DIODE
D521 MTZJ6.8C-T2 Z DIODE
D535 1SS133-T2 SI DIODE IM
D541 1SS133-T2 SI DIODE IM
D543 1SS133-T2 SI DIODE IM
D546 1SS133-T2 SI DIODE IM
D548 1SS133-T2 SI DIODE IM
D549 1SS133-T2 SI DIODE IM
D550 1SS133-T2 SI DIODE IM
D551 1SS133-T2 SI DIODE IM
D553 1SS133-T2 SI DIODE IM
D561 SLR-342MC-T12 LED
D611 1SS133-T2 SI DIODE IM
D612 1SS133-T2 SI DIODE IM
D2101 1SS133-T2 SI DIODE IM
D2201 1SS133-T2 SI DIODE IM
D2301 1SS133-T2 SI DIODE IM
D2401 1SS133-T2 SI DIODE IM
D2501 1SS133-T2 SI DIODE IM
D2601 1SS133-T2 SI DIODE IM
D2701 MTZJ15C-T2 Z DIODE
D2702 MTZJ15C-T2 Z DIODE
D2703 MTZJ16C-T2 Z DIODE
D2704 1SS133-T2 SI DIODE IM
D2705 1SS133-T2 SI DIODE IM
D3101 1SS133-T2 SI DIODE IM
D3102 1SS133-T2 SI DIODE IM
D3201 1SS133-T2 SI DIODE IM
D3202 1SS133-T2 SI DIODE IM
D3301 1SS133-T2 SI DIODE IM
D3302 1SS133-T2 SI DIODE IM
D3401 1SS133-T2 SI DIODE IM
D3402 1SS133-T2 SI DIODE IM
D3501 1SS133-T2 SI DIODE IM
D3502 1SS133-T2 SI DIODE IM
D3601 1SS133-T2 SI DIODE IM
D3602 1SS133-T2 SI DIODE IM
D3703 MTZJ15C-T2 Z DIODE
 C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C153 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C154 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C155 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C156 NCF21HZ-473X C CAPACITOR 0.047uF 50V Z
C157 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C159 NCF21HZ-223X C CAPACITOR 0.022uF 50V Z
C161 QEZ0736-478 E CAPACITER 4700uF C30J,C30C
C161 QETM1HM-338 E CAPACITOR 3300uF 50V M C20J,C20C
C162 QEZ0736-478 E CAPACITER 4700uF C30J,C30C
 Symbol No. Part No. Part Name Description Local
