JVC TH-C30J - Page 54

3-20
DVD loading board
Block No. [0][5]
CN702 QGF1016C6-18W CONNECTOR FFC/FPC (1-18)
CN801 QGF1016C6-05W CONNECTOR FFC/FPC (1-5)
CN811 QGA2001F6-05X CONNECTOR W-B (1-5)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K353 NQR0502-001X FERRITE BEADS
K354 NQR0022-002X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K701 NQR0022-002X FERRITE BEADS
K702 NQR0022-002X FERRITE BEADS
K703 NQR0022-002X FERRITE BEADS
K704 NQR0022-002X FERRITE BEADS
K705 NQR0022-002X FERRITE BEADS
K706 NQR0022-005X FERRITE BEADS
K707 NQR0022-002X FERRITE BEADS
K708 NQR0022-002X FERRITE BEADS
K709 NQR0022-002X FERRITE BEADS
K710 NQR0022-002X FERRITE BEADS
K711 NQR0022-002X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K721 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K722 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K726 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K810 NQR0502-001X FERRITE BEADS
K811 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K812 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
TH301 NAD0025-103X N THERMISTOR 10k Ω
X301 NAX0741-001X CRYSTAL
X302 NAX0376-002X CRYSTAL
X451 NAX0248-001X C OSCILLATOR
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1CM-107Z E CAPACITOR 100uF 16V M
C2 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C7 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
CN1 QGF1036F2-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-002 PUSH SWITCH
SW2 QSW0844-002 PUSH SWITCH
SW3 QSW0844-002 PUSH SWITCH
SW4 QSW0844-002 PUSH SWITCH
SW5 QSW0844-002 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW7 QSW0886-002 DETECT SWITCH
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
