JVC TH-C60J User Manual

1-10 (No.MB511)
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the metal cover
(See Fig.1 and 2)
(1) Remove the three screws A attaching the metal cover.
(See Fig.1)
(2) Remove the four screws B attaching the metal cove. (See
Fig.2)
Fig.1
Fig.2
A
B

JVC TH-C60J Specifications

General

Brand	JVC
Model	TH-C60J
Category	Home Theater System
Language	English
