JVC TH-C60J

1-16 (No.MB511)
3.2.2 Removing the rear plate
(See Fig.4 and 5)
(1) Disconnect the connector wire from connector CN371
of
the mother board. (See Fig.4)
(2) Remove the six screws C and one screw D attaching the
rear plate (See Fig.5)
Fig.4
Fig.5
CN371
C
CC
D
