4 mm
2. Firmly x 1 dowel into each hole in the wall if necessary. Tighten the wall mount
brackets on the wall with screws and screwdriver (not included). Make sure that they
are securely installed.
ø2.5~3mm
ø ~6mm
Ensure mounting screws are in the centre of the timber stud.
3. Lift the unit onto the wall mount brackets and slot into place.
Wall mounting with dowels and screws
Wall mounting with screws only
To mount the soundbar, the screw head must be aligned with the mounting hole of the unit.
