JVC TH-D337B

9
3 mm
710 mm
Loosen the screws
COAXIAL
(TV/BD/DVD)
OPTICAL
(TV/BD/DVD)
AC~
SERVICE ONLY AUX (BD/DVD) SUBWOOFER OUT
4. Loosen the screws at the back of the unit. Leave approximately 3 mm between the
screw head and the surface of the unit
5. Lift the unit onto the wall mount brackets
and slot into place.
