JVC UX-A52R Service Manual

UX-A52R
3-15
R2750 NRSA63J-221X MG RESISTOR
R2751 NRSA63J-221X MG RESISTOR
R2752 NRSA63J-221X MG RESISTOR
R2852 NRSA63J-100X MG RESISTOR
R2853 NRSA63J-222X MG RESISTOR
R2854 NRSA63J-222X MG RESISTOR
R2855 NRSA63J-100X MG RESISTOR
R2856 QRE141J-9R1Y C RESISTOR 9.1 5% 1/4W
R2860 NRSA63J-100X MG RESISTOR
R2861 NRSA63J-222X MG RESISTOR
R2862 NRSA63J-222X MG RESISTOR
R2863 NRSA63J-103X MG RESISTOR
R2864 NRSA63J-103X MG RESISTOR
R2865 NRSA63J-103X MG RESISTOR
R2866 NRSA63J-103X MG RESISTOR
R2867 NRSA63J-100X MG RESISTOR
R2901 NRSA63J-103X MG RESISTOR
R3101 NRSA63J-220X MG RESISTOR
R3102 NRSA63J-182X MG RESISTOR
R3103 NRSA63J-242X MG RESISTOR
R3105 NRSA63J-104X MG RESISTOR
R3106 NRSA63J-332X MG RESISTOR
R3107 NRSA63J-123X MG RESISTOR
R3108 NRSA63J-562X MG RESISTOR
R3109 NRSA63J-102X MG RESISTOR
R3110 NRSA63J-272X MG RESISTOR
R3111 NRSA63J-363X MG RESISTOR
R3112 NRSA63J-222X MG RESISTOR
R3116 NRSA63J-102X MG RESISTOR
R3121 NRSA63J-223X MG RESISTOR
R3201 NRSA63J-220X MG RESISTOR
R3202 NRSA63J-182X MG RESISTOR
R3203 NRSA63J-242X MG RESISTOR
R3205 NRSA63J-104X MG RESISTOR
R3206 NRSA63J-332X MG RESISTOR
R3207 NRSA63J-123X MG RESISTOR
R3208 NRSA63J-562X MG RESISTOR
R3209 NRSA63J-102X MG RESISTOR
R3210 NRSA63J-272X MG RESISTOR
R3211 NRSA63J-363X MG RESISTOR
R3212 NRSA63J-222X MG RESISTOR
R3216 NRSA63J-102X MG RESISTOR
R3221 NRSA63J-223X MG RESISTOR
R3301 NRS181J-221X MG RESISTOR VCC
R3303 NRSA63J-393X MG RESISTOR
R3304 NRS181J-101X MG RESISTOR VCC
R3305 NRSA63J-222X MG RESISTOR
R3310 QRJ146J-4R7X UNF C RESISTOR 4.7 5% 1/4W
R3313 NRSA63J-2R2X MG RESISTOR
R3314 NRSA63J-153X MG RESISTOR
R3315 NRSA63J-101X MG RESISTOR DUMP
R3327 NRSA63J-474X MG RESISTOR BIAS T.P
R3335 NRSA63J-152X MG RESISTOR BIAS SW
R3336 NRSA63J-472X MG RESISTOR
R3337 NRSA63J-332X MG RESISTOR
R3338 NRSA63J-392X MG RESISTOR
R3339 NRSA63J-222X MG RESISTOR
R3340 NRS181J-0R0X MG RESISTOR VDD
R3341 NRSA63J-123X MG RESISTOR
R3342 NRSA63J-203X MG RESISTOR
R3343 NRSA63J-183X MG RESISTOR
R3353 QRZ9005-100X F RESISTOR
A
+B
R3371 NRSA63J-103X MG RESISTOR
R3372 NRSA63J-102X MG RESISTOR
R3375 NRSA02J-151X MG RESISTOR 1/8W
R3376 NRSA02J-683X MG RESISTOR
SP709 LV30064-092A SPACER
VR331 QVP0077-203Z SEMI V RESISTOR BIAS ADJ
VR337 QVP0077-103Z SEMI V RESISTOR TAPE SPEED ADJ
W 708 QJQ009-032601 SHI CR B-B WIRE DIGITAL OUTPUT
W 709 QUB230-22HPHP SIN TWIST WIRE
X2701 QAX0283-001Z C RESONATOR MAIN CLOCK
X2702 QAX0401-001 CRYSTAL SUB CLOCK
Item
Parts number Parts name Ar
e
a
Electrical parts list (Front board)
Remarks
Block No. 02
A
Item
Parts number Parts name Ar
e
a
Remarks
A
