JVC UX-A52R Service Manual

UX-A52R
3-16
Item
Parts number Parts name Ar
e
a
Electrical parts list (Tuner board)
Remarks
Block No. 03
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C 1 NCB21HK-223X C CAPACITOR
C 2 NCB21HK-103X C CAPACITOR
C 3 EETC1CM-106ZJC E CAPACITOR
C 4 NCB21HK-103X C CAPACITOR
C 6 NCB21HK-222X C CAPACITOR
C 7 NCB21HK-102X C CAPACITOR
C 8 NCB21HK-102X C CAPACITOR
C 9 NCB21HK-102X C CAPACITOR
C 10 NCS21HJ-120X C CAPACITOR
C 11 NCB21HK-223X C CAPACITOR
C 12 NCB21HK-473X C CAPACITOR
C 13 NCS21HJ-120X C CAPACITOR
C 14 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 15 NCS21HJ-120X C CAPACITOR
C 16 NCS21HJ-120X C CAPACITOR
C 17 NCB21HK-392X C CAPACITOR
C 18 QEQ61HM-474Z NP E CAPACITOR .47MF 20% 50V
C 19 NCB21HK-473X C CAPACITOR
C 20 NCB21HK-102X C CAPACITOR
C 21 NCB21HK-223X C CAPACITOR
C 22 NCS21HJ-151X C CAPACITOR
C 23 NCS21HJ-151X C CAPACITOR
C 24 NCS21HJ-151X C CAPACITOR
C 25 QEKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 26 NCB21HK-103X C CAPACITOR
C 27 NCB21HK-102X C CAPACITOR
C 30 EETC1CM-107ZJC E CAPACITOR
C 31 EEKC1CM-226ZJC E CAPACITOR
C 32 NCB21HK-473X C CAPACITOR
C 33 NCB21HK-473X C CAPACITOR
C 34 NCB21HK-223X C CAPACITOR
C 35 NCB21HK-473X C CAPACITOR
C 36 EEKC1HM-105ZJC E CAPACITOR
C 37 EEKC1HM-105ZJC E CAPACITOR
C 38 EETC1HM-224ZJC E CAPACITOR
C 39 EETC1HM-105ZJC E CAPACITOR
C 40 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 41 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 42 NCB21HK-182X C CAPACITOR
C 43 NCB21HK-182X C CAPACITOR
C 44 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 45 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C 46 NCB21HK-223X C CAPACITOR
C 47 EETC1HM-105ZJC E CAPACITOR
C 48 NCB21HK-222X C CAPACITOR
C 49 NCS21HJ-471X C CAPACITOR
C 50 EETC1CM-226ZJC E CAPACITOR
C 51 EEKC1HM-105ZJC E CAPACITOR
C 52 QFVJ1HJ-274Z MF CAPACITOR .27MF 5% 50V
C 53 EETC1CM-226ZJC E CAPACITOR
C 54 NCB21HK-473X C CAPACITOR
C 55 NCS21HJ-330X C CAPACITOR
C 56 NCS21HJ-100X C CAPACITOR
C 57 NCB21HK-102X C CAPACITOR
C 58 NCB21HK-473X C CAPACITOR
C 59 NCB21HK-102X C CAPACITOR
C 70 NCS21HJ-220X C CAPACITOR
C 71 NCS21HJ-220X C CAPACITOR
C 72 NCB21HK-561X C CAPACITOR
C 73 NCB21HK-104X C CAPACITOR
C 74 NCB21HK-104X C CAPACITOR
C 75 EETC1HM-106ZJC E CAPACITOR
C 76 NCB21HK-331X C CAPACITOR
CF 1 QAX0420-001 C FILTER
CF 2 QAX0458-001Z C FILTER
CF 3 QAX0610-001Z C DISCRIMINATOR
CN 1 QGF1205F1-13 CONNECTOR
D 1 1SS133-T2 SI DIODE
D 2 1SS133-T2 SI DIODE
D 3 1SS133-T2 SI DIODE
D 4 1SS133-T2 SI DIODE
D 11 1SS133-T2 SI DIODE
IC 1 LA1838 IC
IC 2 LC72136N IC
IC 3 LC72723 IC(RDS)
J 1 QNB0014-001 ANT TERMINAL
L 1 QQR1094-001 COIL BLOCK
L 2 QQL231K-330Y INDUCTOR
L 3 QQL231K-4R7Y INDUCTOR
L 70 QQL231K-101Y INDUCTOR
Q
1 2SC2814/4-5/-X TRANSISTOR
Q
2 2SD601A/QR/-X TRANSISTOR
Q
3 2SD601A/QR/-X TRANSISTOR
Q
4 KRA107S-X TRANSISTOR
Q
5 KRA107S-X TRANSISTOR
R 2 NRSA02J-331X MG RESISTOR
R 3 NRSA02J-224X MG RESISTOR
R 4 NRSA02J-331X MG RESISTOR
R 5 NRSA02J-120X MG RESISTOR
R 6 NRSA02J-120X MG RESISTOR
R 10 NRSA02J-222X MG RESISTOR
R 11 NRSA02J-472X MG RESISTOR
R 12 NRSA02J-472X MG RESISTOR
R 13 NRSA02J-103X MG RESISTOR
R 14 NRSA02J-104X MG RESISTOR
R 15 NRSA02J-332X MG RESISTOR
R 16 NRSA02J-472X MG RESISTOR
R 17 QRZ9005-680X F RESISTOR
A
68 1/4W
R 18 NRSA02J-102X MG RESISTOR
R 19 NRSA02J-102X MG RESISTOR
R 20 NRSA02J-102X MG RESISTOR
R 21 NRSA02J-562X MG RESISTOR
R 22 NRSA02J-222X MG RESISTOR
R 23 NRSA02J-822X MG RESISTOR
R 24 NRSA02J-103X MG RESISTOR
R 25 NRSA02J-331X MG RESISTOR
R 26 NRSA02J-222X MG RESISTOR
R 27 NRSA02J-103X MG RESISTOR
R 28 NRSA02J-103X MG RESISTOR
R 29 NRSA02J-103X MG RESISTOR
R 30 NRSA02J-122X MG RESISTOR
R 31 NRSA02J-102X MG RESISTOR
R 32 NRSA02J-102X MG RESISTOR
R 33 NRSA02J-331X MG RESISTOR
R 34 NRSA02J-470X MG RESISTOR
R 35 NRSA02J-562X MG RESISTOR
R 36 NRSA02J-332X MG RESISTOR
R 37 NRSA02J-103X MG RESISTOR
R 38 NRSA02J-393X MG RESISTOR
R 39 NRSA02J-393X MG RESISTOR
R 40 NRSA02J-273X MG RESISTOR
R 41 NRSA02J-332X MG RESISTOR
R 60 NRSA02J-0R0X MG RESISTOR
R 72 NRSA02J-102X MG RESISTOR
R 73 NRSA02J-102X MG RESISTOR
T 1 QQR0793-001 IFT
