UX-A52R
3-17
Item
Parts number Parts name Ar
e
a
Electrical parts list (Tuner board)
Remarks
Block No. 03
A
TU 1 QAU0160-001 FRONT END
X 1 QAX0402-001 CRYSTAL
X 70 QAX0263-001Z CRYSTAL
