1-43
UX-A70MD
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Reference voltage output.
Equalizer center frequency setting pin.
BPF3T center frequency setting pin.
Power supply.
BPF22 center frequency setting pin.
Tracking error signal output.
Connects the sled error signal LPF capacitor.
Sled error signal output.
ADIP FM signal output.
ADIP signal comparator input.
Connects the ADIPAGC capacitor.
ADIP2 binary value signal output.
13 output / temperature signal output. Switched with serial commands.
Focus error signal output.
Reflection light quantity signal output for the main beam servo detector.
RF/ABCD bottom hold signal output.
Peak hold signal output for the RF/ABCD signals.
RF equalizer output.
Connects the RFAGC capacitor.
RFAGC input.
User comparator output.
User comparator non-inverted input.
Connects the capacitor for ADIP amplifier feedback circuit.
User operational amplifier output.
User operational amplifier inverted input.
RF amplifier output. Eye pattern checkpoint.
Input of the groove RF signal with AC coupling.
Groove RF signal output.
VREF
EQADJ
3TADJ
Vcc
WBLADJ
TE
CSLED
SE
ADFM
ADIN
ADAGC
ADFG
AUX
FE
ABCD
BOTM
PEAK
RF
RFAGC
AGCI
COMPO
COMPP
ADDC
OPO
OPN
RFO
MORFI
MORFO
O
I/O
I/O
-
I/O
O
-
O
O
I
-
O
O
O
O
O
O
O
-
I
O
I
I/O
O
I
O
I
O
Pin No.
Symbol
I/O
Function
