1-50
UX-A70MD
1 2 3 4 5 6 7 8 9
10
GND OUT1 P1
VZ IN1 IN2
VCC1
VCC2 P2
OUT2
Input Output
Mode
IN1 IN2 OUT1 OUT2
Brake
0 0 0 0
1 0 1 0
0 1 0 1
1 1 0 0
CLOCKWISE
COUNTER-CLOCKWISE
Brake
LB1641 (IC851,IC852) : DC motor driver
1. Pin layout
2. Pin function
