JVC UX-A70MD User Manual

3-19
UX-A70MD
Item
Parts number Parts name Area
Remarks
A
Electrical parts list (MD servo board)
Block No. 05
Item
Parts number Parts name Area
Remarks
A
C 300 NCF31CZ-104X C CAPACITOR
C 302 NCF31CZ-104X C CAPACITOR
C 307 NCB31HK-222X C CAPACITOR
C 310 NCB31HK-102X C CAPACITOR
C 311 NCF21CZ-105X C CAPACITOR
C 312 NEA70GM-476X E CAPACITOR
C 314 NCB31EK-223X C CAPACITOR
C 315 NCB31HK-102X C CAPACITOR
C 316 NCF21CZ-105X C CAPACITOR
C 318 NCB31HK-682X C CAPACITOR
C 319 NCB31CK-333X C CAPACITOR
C 320 NCB21AK-105X C CAPACITOR
C 321 NCB31HK-472X C CAPACITOR
C 322 NCB21AK-105X C CAPACITOR
C 323 NCB31HK-682X C CAPACITOR
C 324 NCB21CK-224X C CAPACITOR
C 325 NCB31CK-103X C CAPACITOR
C 326 NCB31EK-223X C CAPACITOR
C 327 NCB31CK-104X C CAPACITOR
C 328 NCB31CK-104X C CAPACITOR
C 330 NCF31CZ-104X C CAPACITOR
C 333 NCB21CK-154X C CAPACITOR
C 334 NCF31CZ-104X C CAPACITOR
C 340 NCB31EK-223X C CAPACITOR
C 341 NCB31EK-223X C CAPACITOR
C 342 NCF31CZ-104X C CAPACITOR
C 350 NEA70GM-476X E CAPACITOR
C 351 NCF21CZ-105X C CAPACITOR
C 352 NEA70GM-476X E CAPACITOR
C 353 NCF21CZ-105X C CAPACITOR
C 354 NCF21CZ-105X C CAPACITOR
C 355 NCF31CZ-104X C CAPACITOR
C 358 NCF31CZ-104X C CAPACITOR
C 359 NCF31CZ-104X C CAPACITOR
C 361 NCF31CZ-104X C CAPACITOR
C 375 NCB31CK-103X C CAPACITOR
C 376 NCB21CK-474X C CAPACITOR
C 377 NCS31HJ-471X C CAPACITOR
C 378 NCS31HJ-330X C CAPACITOR
C 379 NCB21CK-474X C CAPACITOR
C 380 NCB31CK-153X C CAPACITOR
C 390 NCB10JM-106X C CAPACITOR
C 400 NEAD1CM-226X E CAPACITOR
C 401 NEAD0JM-107X E CAPACITOR
C 402 NCB31HK-331X C CAPACITOR
C 403 NEAD0GM-476X E CAPACITOR
C 407 NCS31HJ-101X C CAPACITOR
C 408 NCS31HJ-101X C CAPACITOR
C 409 NCB31CK-104X C CAPACITOR
C 411 NCF21CZ-105X C CAPACITOR
C 412 NCF31CZ-104X C CAPACITOR
C 415 NCB31CK-103X C CAPACITOR
C 421 NCB31HK-561X C CAPACITOR
C 423 NCB31HK-561X C CAPACITOR
C 425 NCB31HK-561X C CAPACITOR
C 427 NCB31HK-561X C CAPACITOR
C 429 NCB31HK-392X C CAPACITOR
C 431 NCB31HK-392X C CAPACITOR
C 433 NCB31HK-562X C CAPACITOR
C 435 NCB31HK-562X C CAPACITOR
C 437 NCB31HK-103X C CAPACITOR
C 439 NCB31HK-103X C CAPACITOR
C 450 NEA71CM-107X E CAPACITOR
C 451 NEA70GM-107X E CAPACITOR
C 452 NCF31CZ-104X C CAPACITOR
C 453 NCF31CZ-104X C CAPACITOR
C 455 NDC32AJ-101X C CAPACITOR
C 480 NEA70JM-476X E CAPACITOR
C 481 NCF21CZ-105X C CAPACITOR
C 482 NEA70JM-226X E CAPACITOR
C 483 NCF31CZ-104X C CAPACITOR
C 484 NEAD1CM-106X E CAPACITOR
C 485 NCF31CZ-104X C CAPACITOR
C 486 NCF31CZ-104X C CAPACITOR
C 487 NCF31CZ-104X C CAPACITOR
C 488 NEAD1CM-106X E CAPACITOR
C 489 NEAD1VM-475X E CAPACITOR
C 490 NCB31CK-103X C CAPACITOR
C 491 NCB31HK-222X C CAPACITOR
C 492 NCB31HK-222X C CAPACITOR
C 493 NCF21CZ-105X C CAPACITOR
C 496 NCF21CZ-105X C CAPACITOR
C 497 NCF31CZ-104X C CAPACITOR
C 501 NCS31HJ-180X C CAPACITOR
C 502 NCS31HJ-180X C CAPACITOR
C 511 NCF31CZ-104X C CAPACITOR
C 512 NCF31CZ-104X C CAPACITOR
C 515 NCF31CZ-104X C CAPACITOR
C 590 NCS31HJ-101X C CAPACITOR
C 591 NCF31CZ-104X C CAPACITOR
CN321 QGF0501F2-21X CONNECTOR FOR PICK-UP A'S
CN407 QGF1006F2-08W SOCKET FOR CAM SW
CN408 QGF1006F2-09W CONNECTOR FOR TRAMECHA PW
CN451 QGF1016F2-04W CONNECTOR FOR HEAD
CN521 QGF1006F2-21W SOCKET FOR SYSTEM
CN601 QGF1006F2-09W CONNECTOR
D 310 1SS355-X DIODE TEMP DET
D 451 RB160L-60-X SB DIODE
D 452 RB160L-60-X SB DIODE
IC310 CXA2523AR IC RF
IC340 TC7S08F-W IC APC PWM BUFFER
IC350 CXD2662R IC
IC390 HY51V17400CT-60 IC 4M*4 DRAM
IC400 XC62ER3602M-X IC
IC410 M63008FP-X IC BTL DRIVER
IC450 BD7910FV-X IC DRIVER
IC480 AK4519VF-X IC
IC485 TK11140SC-W IC
IC500 HD6432345A15FA IC(MCU)
IC590 AK93C65AF-X IC 256*16BIT EEPRO
K 346 NQR0360-001X FERRITE BEADS
K 353 NQR0389-003X FERRITE BEADS
K 491 NQR0022-005X FERRITE BEADS
K 492 NQR0022-005X FERRITE BEADS
K 495 NQR0022-005X FERRITE BEADS
K 496 NQR0022-005X FERRITE BEADS
K 505 NQR0389-003X FERRITE BEADS
K 521 NQR0354-001X FERRITE BEADS
K 522 NQR0354-001X FERRITE BEADS
K 523 NQR0389-003X FERRITE BEADS
K 524 NQR0389-003X FERRITE BEADS
L 351 NQL38DK-100X INDUCTOR
L 352 NQL38DK-100X INDUCTOR
L 525 NQL274M-1R5X INDUCTOR
L 526 NQL274M-1R5X INDUCTOR
Q
330 2SA1362/G/-X TRANSISTOR
