1-2 (No.MB634)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section Output Power 8 W per channel min. RMS driven into 4 Ω at 1 kHz with no more than 10% total harmonic
distortion. (IEC268-3)
Speakers/Impedance 4 Ω - 8 Ω
Terminals AUX IN Input sensitivity/Impedance (250mV/50kΩ):USB Ver.2.0 (Full Speed)
Compatible device Mass Storage Class
Compatible File System FAT16, FAT32
Bus Power supply Max 5V/500mA
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM (MW) tuning range 522 kHz - 1 629 kHz
CD player section Dynamic range 70 dB
Signal-to-noise ratio 70 dB
General Power requirement AC 230 V , 50 Hz
Power consumption 32 W (at operation)
0.7 W (on standby)
Dimensions (approx.) 144 mm × 212 mm × 254 mm (W/H/D)
Mass (approx.) 2.5 kg
Speakers Type 1-way Bass reflex
Speaker units 10 cm cone × 1
Impedance 4 Ω
Dimensions (approx.) 136 mm × 212 mm × 178 mm (W/H/D)
Mass (approx.) 1.3 kg each
