(No.MB665<Rev.004>)1-13
3.1.11 Removing the FL board (See Fig.18)
(1) Remove the seven screws M attaching the FL board.
3.1.12 Removing the Volume board (See Fig.18)
(1) Remove the volume knob.
(2) Remove the nine screws N attaching the Volume board.
Fig.18
M
N
N
