JVC UX-G300B User Manual

3-13
Power board
Block No. [0][2]
R3079 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3080 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3081 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3085 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
R3087 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3092 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3093 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3094 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3095 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3098 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
R3098 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J 300A,300US,
300UF,300UN
R3098 NRSA63J-133X MG RESISTOR 13k
Ω 1/16W J 300UW
R3098 NRSA63J-303X MG RESISTOR 30k
Ω 1/16W J 300UG
R3099 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R3105 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R3107 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R3124 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3125 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3144 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3145 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3166 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3179 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3180 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3181 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3187 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3194 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3195 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3198 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3199 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3301 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3302 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3303 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3610 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R3611 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R3702 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J 300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
R3710 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R3711 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R3801 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R5101 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R5102 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R5103 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R5104 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R5105 NRSA63J-433X MG RESISTOR 43k
Ω 1/16W J
R5201 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R5202 NRSA63J-912X MG RESISTOR 9.1k
Ω 1/16W J
R5203 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R5204 NRSA63J-243X MG RESISTOR 24k
Ω 1/16W J
R5205 NRSA63J-433X MG RESISTOR 43k
Ω 1/16W J
R5301 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R5303 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R5304 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5305 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R5306 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R5307 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5308 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R5309 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R5310 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5311 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5313 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5351 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R5352 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R5353 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R5354 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5355 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5356 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R5357 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R5401 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
R5403 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R5404 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5405 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R5406 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J
R5407 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5408 NRSA63J-242X MG RESISTOR 2.4k
Ω 1/16W J
R5409 NRSA63J-474X MG RESISTOR 470k
Ω 1/16W J
R5410 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5411 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5413 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R5501 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5502 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5503 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R5504 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R5505 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R5506 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
R5507 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R5508 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5509 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5601 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5602 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5603 NRSA63J-563X MG RESISTOR 56k
Ω 1/16W J
R5604 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R5605 NRSA63J-113X MG RESISTOR 11k
Ω 1/16W J
R5606 NRSA63J-220X MG RESISTOR 22
Ω 1/16W J
R5607 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R5801 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R5901 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
CN302 QGB2510J1-06 CONNECTOR B-B (1-6)
CN303 QGF1208C1-05 CONNECTOR FFC/FPC (1-5)
CN304 QGF1208C1-13 CONNECTOR FFC/FPC (1-
13)
CN306 QGF1208F1-15 CONNECTOR FFC/FPC (1-
15)
300B,300E,
300EN,300EV,
303E,303EN,
303EV,305E,
305EN,305EV
CN306 QGF1208F1-11 CONNECTOR FFC/FPC (1-
11)
300A,300US,
300UF,300UT,
300UW,300UG,
300UN,305UT
CN311 QGF1040C1-25 CONNECTOR FFC/FPC (1-
25)
CN312 QGB1214J1-08S CONNECTOR B-B (1-8)
CN520 QGF1208C1-11 CONNECTOR FFC/FPC (1-
11)
EP360 QNZ0136-001Z EARTH PLATE
K3501 NQR0627-002X FERRITE 1.5K/
100MHz200mA
0.4R
K5801 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
X3001 QAX0711-002Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
IC600 R2A15108SP-X IC
Q6001 KRC110S-X DIGI TRANSISTOR
D6402 MC2838-X DIODE
D6601 MC2838-X DIODE
D6602 MA8033-X Z DIODE
C6001 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6002 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6003 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6005 NCB31CK-334X C CAPACITOR 0.33uF 16V K
C6006 QETN1EM-476Z E CAPACITOR 47uF 25V M
C6007 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6008 NCB31CK-104X C CAPACITOR 0.1uF 16V K 300UT,305UT
C6052 QEZ0863-106Z M CAPACITOR 10uF
