1-2 (No.MB431)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section Output Power 100 W (50 W+50 W) at 6 Ω (10% THD)
Speakers Impedance 6 Ω - 16 Ω
Audio Input AUX 400 mV/50 kΩ
Tuner section FM tuning range 87.50 MHz - 108.00 MHz
AM tuning range 531 kHz - 1 710 kHz (at 9 kHz)
530 kHz - 1 710 kHz (at 10 kHz)
CD player section Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
Cassette deck section Frequency response: Normal (type l) 60 Hz - 14 000 Hz
Wow and flutter 0.15% (WRMS)
General Power requirement AC 110 V - 127 V / 220 V - 240 V (adjustable with the voltage selector),
50 Hz/60 Hz
Power consumption 90 W (at operation)
0.8 W (on standby)
Dimensions (approx.) 175 mm × 232 mm × 412 mm (W/H/D)
Mass (approx.) 6.6 kg
Speakers Type 2-way Bass reflex
Speaker units Woofer 10 cm cone × 1
Tweeter 4 cm cone × 1
Impedance 6 Ω
Dimensions (approx.) 144 mm × 231 mm × 201 mm (W/H/D)
Mass (approx.) 2.0 kg each
