JVC UX-G5

3-9
Front board
Block No. [0][2]
R629 BIRC1220105A00 C RESISTOR 1.2K Ω 1/10W
R630 BIRC1220105A00 C RESISTOR 1.2K
Ω 1/10W
R631 BIRC5630105A00 C RESISTOR 56K
Ω 1/10W
R632 BIRC5630105A00 C RESISTOR 56K
Ω 1/10W
R633 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R635 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R636 BIRC4720085M00 C RESISTOR 4.7K
Ω 1/8W J C
R637 BIRC2210045M00 C RESISTOR 220
Ω J C 1/4W
R638 BIRC2210045M00 C RESISTOR 220
Ω J C 1/4W
R641 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R642 BIRC1020085M00 C RESISTOR 1K
Ω 1/8W J
R643 BIRC2020105A00 C RESISTOR 2K
Ω 1/10W
R644 BIRC2020105A00 C RESISTOR 2K
Ω 1/10W
R645 BIRC6830105A00 C RESISTOR 68K
Ω 1/10W
R646 BIRC6830105A00 C RESISTOR 68K
Ω 1/10W
R661 BIRC1830105A00 C RESISTOR 18K
Ω 1/10W
R662 BIRC1830105A00 C RESISTOR 18K
Ω 1/10W
R663 BIRC1220105A00 C RESISTOR 1.2K
Ω 1/10W
R664 BIRC1220105A00 C RESISTOR 1.2K
Ω 1/10W
R671 BIRC8220105A00 C RESISTOR 8.2K
Ω 1/10W
R672 BIRC8220105A00 C RESISTOR 8.2K
Ω 1/10W
R673 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R674 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R681 BIRC5630085M00 C RESISTOR 56K
Ω
R682 BIRC5630085M00 C RESISTOR 56K Ω
R683 BIRC1520105A00 C RESISTOR 1.5K Ω
R684 BIRC1520105A00 C RESISTOR 1.5K Ω
R688 BIRC4710105A00 C RESISTOR 470 Ω 1/10W
R689 BIRC4700105A00 C RESISTOR 47
Ω 1/10W
R690 BIRC1040105A00 C RESISTOR 100K
Ω 1/10W
R691 BIRC3320105A00 C RESISTOR 3.3K
Ω 1/10W
L311 BI603141V COIL OSC
L402 BI26100000KN00 FIXED INDUCTOR 10UH
L403 BI26100000KN00 FIXED INDUCTOR 10UH
L661 BI18A843556N00 FILTER BEAD 843556
L682 BI18A843556N00 FILTER BEAD 843556
CN301 BI12S700221V SOCKET 7P
CN302 BI12P70094V CONNECTOR WIRE 7P for CASS MECH
CN401 BI12S280004U SOCKET 28P
CN402 BI12S160033V SOCKET 16P
CN501 BI12S150029V CONNECTOR 15P
CN601 BI12S80059V CONNECTOR 8P
CN661 BI12S120052V SOCKET 12P
CN671 BI12S30039V CONNECTOR 3P
CN681 BI12SBI120047U SOCKET 12P
JR603 BIRC0000105A00 C RESISTOR 0
Ω
X401 BI29ZTA8.00P015 C RESONTOR 8MHz
X402 BI2101012 CRYSTAL 32.768KHz
XXXXX BI12P70096V CONNECTOR WIRE
7P for MAIN CN301
to CASS MECH
XXXXX BI11B030B0V WIRE 30mm WIRE
ZD401 UZ3.9BSB Z DIODE BI3UZ3.9BSBM000
ZD601 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
ZD602 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
 Symbol No. Part No. Part Name Description Local
IC351 RPM7138-V4 IC BI115291
IC352 PT6524LQ IC BI118101
Q351 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q352 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
Q353 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
D351 SLR-342VCT31 LED BI28SLR342VP01
D358 1SS133 FR DIODE BI31SS133M000V7
D359 1SS133 FR DIODE BI31SS133M000V7
D360 1SS133 FR DIODE BI31SS133M000V7
D361 1SS133 FR DIODE BI31SS133M000V7
 Symbol No. Part No. Part Name Description Local
D362 1SS133 FR DIODE BI31SS133M000V7
D363 1SS133 FR DIODE BI31SS133M000V7
D581 ISS355 DIODE BI31SS355A0077
D582 ISS355 DIODE BI31SS355A0077
D591 1SS133 FR DIODE BI31SS133M000V7
D592 1SS133 FR DIODE BI31SS133M000V7
C351 BICC103500KA04 C CAPACITOR 0.01uF 50V
C353 BICC102500KA04 C CAPACITOR 1000pF 50V
C354 BICE107100MP11 E CAPACITOR 100uF 10V
C355 BICE107100MP11 E CAPACITOR 100uF 10V
C356 BICC103500KA04 C CAPACITOR 0.01uF 50V
C357 BICC103500KA04 C CAPACITOR 0.01uF 50V
C358 BICC102500KA04 C CAPACITOR 1000pF 50V
C359 BICC103500KA04 C CAPACITOR 0.01uF 50V
C360 BICC103500KA04 C CAPACITOR 0.01uF 50V
C361 BICC103500KA04 C CAPACITOR 0.01uF 50V
C362 BICC103500KA04 C CAPACITOR 0.01uF 50V
C363 BICC103500KA04 C CAPACITOR 0.01uF 50V
C581 BICC102500KA04 C CAPACITOR 1000pF 50V
C582 BICC102500KA04 C CAPACITOR 1000pF 50V
C583 BICC102500KA04 C CAPACITOR 1000pF 50V
C584 BICC102500KA04 C CAPACITOR 1000pF 50V
C591 BICC102500KA04 C CAPACITOR 1000pF 50V
C592 BICC102500KA04 C CAPACITOR 1000pF 50V
C593 BICC220500JA04 C CAPACITOR 22pF 50V
C594 BICC104500ZA04 C CAPACITOR 0.1uF 50V
C595 BICC104500ZA04 C CAPACITOR 0.1uF 50V
R353 BIRC9110105A00 C RESISTOR 910
Ω 1/10W
R354 BIRC1120105A00 C RESISTOR 1.1K
Ω 1/10W
R355 BIRC1320105A00 C RESISTOR 1.3K
Ω 1/10W
R356 BIRC1820105A00 C RESISTOR 1.8K
Ω 1/10W
R357 BIRC2020105A00 C RESISTOR 2K
Ω 1/10W
R358 BIRC3020105A00 C RESISTOR 3K
Ω 1/10W
R359 BIRC3920105A00 C RESISTOR 3.9K
Ω 1/10W
R360 BIRC6220105A00 C RESISTOR 6.2K
Ω 1/10W
R361 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R363 BIRC9110105A00 C RESISTOR 910
Ω 1/10W
R364 BIRC1120105A00 C RESISTOR 1.1K
Ω 1/10W
R365 BIRC1320105A00 C RESISTOR 1.3K
Ω 1/10W
R366 BIRC1820105A00 C RESISTOR 1.8K
Ω 1/10W
R368 BIRC2210105A00 C RESISTOR 220
Ω 1/10W
R370 BIRC2210105A00 C RESISTOR 220
Ω 1/10W
R371 BIRC4710105A00 C RESISTOR 470
Ω 1/10W
R372 BIRC1810105A00 C RESISTOR 180
Ω 1/10W
R373 BIRC1810105A00 C RESISTOR 180
Ω 1/10W
R374 BIRC1510105A00 C RESISTOR 150
Ω 1/10W
R375 BIRC1510105A00 C RESISTOR 150
Ω 1/10W
R376 BIRC1040105A00 C RESISTOR 100K
Ω 1/10W
R377 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R378 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R379 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R380 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R381 BIRC1020105A00 C RESISTOR 1K
Ω 1/10W
R382 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R383 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R384 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
R386 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R391 BIRC2020105A00 C RESISTOR 2K
Ω 1/10W
R392 BIRC3020105A00 C RESISTOR 3K
Ω 1/10W
R393 BIRC3920105A00 C RESISTOR 3.9K
Ω 1/10W
R394 BIRC6220105A00 C RESISTOR 6.2K
Ω 1/10W
R581 BIRC2230105A00 C RESISTOR 22K
Ω 1/10W
R582 BIRC2230105A00 C RESISTOR 22K
Ω 1/10W
R583 BIRC2720105A00 C RESISTOR 2.7K
Ω 1/10W
R584 BIRC2720105A00 C RESISTOR 2.7K
Ω 1/10W
R585 BIRC8220105A00 C RESISTOR 8.2K
Ω 1/10W
R586 BIRC8220105A00 C RESISTOR 8.2K
Ω 1/10W
R591 BIRC8200105A00 C RESISTOR 82
Ω 1/10W
R592 BIRC8200105A00 C RESISTOR 82
Ω 1/10W
R593 BIRC1010105A00 C RESISTOR 100
Ω 1/10W
VR351 BI804691 RORARY SW RE012304PVB25F
L581 BI26BLM21BA00 COIL BLM21B272S
L591 BI26010000KM00 FIXED INDUCTOR 1uH
BN551 BI12P30250V CONNECTOR WIRE 3P for MAIN CN671
 Symbol No. Part No. Part Name Description Local
