JVC UX-G5 Service Manual

3-10
Power board
Block No. [0][3]
AMP board
Block No. [0][4]
BN591 BI12P402341 CONNECTOR WIRE 4P for AMP CN204
CN351 BI12S160034V SOCKET 16P
J364 1SS133 FR DIODE BI31SS133M000V7
JK552 BI23B0292 HEADPHONE JACK
JK591 BI23B0292 HEADPHONE JACK
S351 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S352 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S353 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S354 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S355 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S356 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S357 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S358 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S359 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S360 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S361 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S362 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S363 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S364 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S365 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S366 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S367 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S368 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
S369 BI8SKRGAED0P0 TACT SWITCH SKRGAED010
XXXXX BI202814010101 HOLDER SENSOR
 Symbol No. Part No. Part Name Description Local
IC901 NJM78L05 IC BI101851
Q903 KTC3199GR TRANSISTOR BI2KTC3199GP000
D901 1N4001 DIODE BI31N40011
D902 1N4001 DIODE BI31N40011
D903 1N4001 DIODE BI31N40011
D904 1N4001 DIODE BI31N40011
D905 1N4001 DIODE BI31N40011
D906 1SS133 FR DIODE BI31SS133M000V7
D907 1SS133 FR DIODE BI31SS133M000V7
C903 BICH104500KM01 C CAPACITOR 0.1uF
C904 BICE477250MP01 E CAPACITOR 470uF 25V
C905 BICE227100MP01 E CAPACITOR 220uF 10V
C906 BICE476160MP01 E CAPACITOR 47uF 16V
C907 BICH472500KM01 C CAPACITOR 4700pF 50V
C908 BICE107100MP01 E CAPACITOR 100uF 10V
R902 BIRC5620085M00 C RESISTOR 5.6K
Ω 1/8W J
R903 BIRC3320085M00 C RESISTOR 3.3K
Ω 1/8W
R905 BIRC3300085M00 C RESISTOR 33
Ω 1/8W
R906 BIRC4720085M00 C RESISTOR 4.7K
Ω 1/8W J C
R907 BIRC1220085M00 C RESISTOR 1.2K
Ω 1/8W
 L901 BI2601102 LINE FILTER
BN903 BI12P60170V CONNECTOR WIRE 6P for AMP CN102
CN901 BI12S200691V CONNECTOR 2P
CN902 BI12S40084V CONNECTOR WIRE
4P for POWER
TRANS
 PT902 BI211011098001 POWER TRANS EI28
 RY901 BI8RL00171V RELAY DC9V 250mW
 SW901 BI805221X POWER SWITCHES SDKGA41301
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC102 NJM79L09 IC BI118381
IC103 KIA7809API IC BI111971V
IC104 KIA7808AP IC BI110891
Q101 KTB1366Y TRANSISTOR BI2KTB1366Y8V
Q102 2SC3052 TRANSISTOR BI2SC3052FA013H
Q121 KTC3198GR TRANSISTOR BI2KTC3198GP000
Q131 2SC3052 TRANSISTOR BI2SC3052FA013H
Q132 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q133 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q134 2SC3052 TRANSISTOR BI2SC3052FA013H
Q151 2SC3052 TRANSISTOR BI2SC3052FA013H
Q153 2SC3052 TRANSISTOR BI2SC3052FA013H
Q154 2SC3052 TRANSISTOR BI2SC3052FA013H
Q155 2SC3052 TRANSISTOR BI2SC3052FA013H
Q157 2SC3052 TRANSISTOR BI2SC3052FA013H
Q171 2SC3052 TRANSISTOR BI2SC3052FA013H
Q172 2SC3052 TRANSISTOR BI2SC3052FA013H
Q201 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q202 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q203 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q204 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q221 2SA1235F TRANSISTOR BI2SA1235FA012H
Q222 2SA1235F TRANSISTOR BI2SA1235FA012H
Q223 2SA1235F TRANSISTOR BI2SA1235FA012H
Q224 2SA1235F TRANSISTOR BI2SA1235FA012H
Q225 2SC3052 TRANSISTOR BI2SC3052FA013H
Q226 2SC3052 TRANSISTOR BI2SC3052FA013H
Q228 2SC3052 TRANSISTOR BI2SC3052FA013H
Q231 2SC5343 TRANSISTOR BI2SC5343GP0000
Q232 2SC5343 TRANSISTOR BI2SC5343GP0000
Q233 2SC3052 TRANSISTOR BI2SC3052FA013H
Q234 2SC3052 TRANSISTOR BI2SC3052FA013H
Q235 2SC3052 TRANSISTOR BI2SC3052FA013H
Q236 2SC3052 TRANSISTOR BI2SC3052FA013H
Q237 2SD1889 TRANSISTOR BI22SD18897V
Q237 2SC3052 TRANSISTOR BI2SC3052FA013H
Q238 2SD1889 TRANSISTOR BI22SD18897V
Q239 2SB1340 TRANSISTOR BI22SB13407V
Q240 2SB1340 TRANSISTOR BI22SB13407V
Q241 2SA1235F TRANSISTOR BI2SA1235FA012H
Q242 2SA1235F TRANSISTOR BI2SA1235FA012H
Q243 KTC3198GR TRANSISTOR BI2KTC3198GP000
Q244 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
Q291 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q292 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q293 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q294 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
D101 1SS133 FR DIODE BI31SS133M000V7
D102 1SS133 FR DIODE BI31SS133M000V7
D103 1SS133 FR DIODE BI31SS133M000V7
D104 1SS133 FR DIODE BI31SS133M000V7
D105 1SS133 FR DIODE BI31SS133M000V7
D131 MC2838 DIODE BI3MC2838A002
D133 1SS133 FR DIODE BI31SS133M000V7
D151 BIRC0000105A00 C RESISTOR 0
Ω 1/10W
D153 1SS133 FR DIODE BI31SS133M000V7
D154 1SS133 FR DIODE BI31SS133M000V7
D157 1SS133 FR DIODE BI31SS133M000V7
D171 RS603M SELEN RECTIFIER BI3RS603M1
D172 RS202 DIODE BI3RS2021
D173 1SS133 FR DIODE BI31SS133M000V7
D201 1SS133 FR DIODE BI31SS133M000V7
D221 1SS133 FR DIODE BI31SS133M000V7
D222 1SS133 FR DIODE BI31SS133M000V7
D223 ISS355 DIODE BI31SS355A0077
D224 ISS355 DIODE BI31SS355A0077
D227 1SS133 FR DIODE BI31SS133M000V7
D228 1SS133 FR DIODE BI31SS133M000V7
D231 1SS133 FR DIODE BI31SS133M000V7
D232 1SS133 FR DIODE BI31SS133M000V7
D233 1SS133 FR DIODE BI31SS133M000V7
D234 ISS355 DIODE BI31SS355A0077
