1-15
UX-G6/FS-G6
31
English
Troubleshooting
If you are having a problem with your system, check this list for a possible solution before calling for service.
If you cannot solve the problem from the hints given here, or the units has been physically damaged, call a qualified
person, such as your dealer, for service.
Symptom
No sound is heard.
Poor radio reception.
Unable to record onto a tape.
The CD skips.
Unable to operate using the remote
control.
Loaded CD and tape cannot be
ejected.
The CD does not play.
Operations are disabled.
Possible Cause
• Connections are incorrect, or
loose.
• Headphones are connected.
• Volume level is set to “– –”.
• The antenna is not connected
correctly.
• The AM loop antenna is too close
to the units.
• The FM antenna is not properly
extended and positioned.
• You are using a tape without a
protect tab.
• Tape-type detection slots are
covered by foreign matters.
• The CD is dirty or scratched.
• The path between the remote
control and the remote sensor on
the front panel is blocked.
• The batteries have lost their
charge.
• The main AC power cord is not
plugged in.
• The system is under the recording
operations.
• The CD is upside down.
• The built-in microprocessor has
malfunctioned due to external
electrical interference.
Action
• Check all connections and make
corrections (see pages 6 – 9).
• Disconnect the headphones (see
page 12).
• Adjust the volume again (see
page 12).
• Reconnect the antenna securely.
• Change the position and direction
of the AM loop antenna.
• Extend FM antenna to the best
reception position (see page 7).
• Cover the hole with adhesive tape
(see page 30).
• Remove the foreign matters.
• Clean or replace the CD (see page
29).
• Remove the obstruction.
• Replace the batteries (see page 6).
• Plug in the AC power plug.
• Stop the recording if required (see
pages 23).
• Put in the CD with the label side
up.
• Unplug the system then plug it
back in.
32
English
Specifications
Stereo Amplifier AX-UXG6
Output power
48 W (24 W + 24 W) at 6 Ω (Max.)
Load impedance: 6 Ω (6 Ω to 16 Ω allowance)
Audio output level/Impedance (at 1 kHz):
Sub Woofer 800 mV/440 Ω
Power requirement: [A] AC 110 V – 120 V/220 V
– 240 V
,
[B] AC 115 V/230 V
(adjustable with the voltage
selector), 50 Hz/60 Hz
Power consumption: [A] 59 W (at operation)
[B] 54 W (at operation)
2.0 W (on standby: with
Dimmer)
Dimensions (approx.): 182 mm x 81 mm x 313 mm
(W/H/D)
Mass (approx.): 3.8 kg
Compact Disc/Tuner XT-UXG6
Audio input sensitivity/Impedance (at 1 kHz):
AUX: 400 mV/47 kΩ
[CD section]
Digital output: OPTICAL DIGITAL OUT
Wow and flutter: Immeasurable
[Tuner section]
FM tuning range: 87.50 MHz – 108.00 MHz
AM tuning range: 531 kHz – 1,710 kHz (at 9 kHz
channel spacing)
530 kHz – 1,710 kHz (at 10 kHz
channel spacing)
Dimensions (approx.): 181 mm x 81 mm x 313 mm
(W/H/D)
Mass (approx.): 1.9 kg
Cassette Deck TD-UXG6
Frequency response :
Normal 30 Hz – 15,000 Hz
High position 30 Hz – 16,000 Hz
Wow and flutter: 0.1 % WRMS
Dimensions (approx.): 181 mm x 81 mm x 304 mm
(W/H/D)
Mass (approx.): 1.9 kg
Speaker System SP-UXG6
Type: 2-way Bass-Reflex Type
Speaker unit: Woofer 11.5 cm Cone x 1
Tweeter 3.0 cm Balanced
Dome x 1
Impedance: 6 Ω
Frequency range: 40 Hz – 20,000 Hz
Sound Pressure Level: 85.5 dB/W•m
Dimensions (approx.): 157 mm x 295 mm x 232 mm
(W/H/D)
Mass (approx.): 3.3 kg each
Supplied Accessories
See page 6.
Design and specifications are subject to change
without notice.
US and foreign patents licensed from Dolby
Laboratories Licensing Corporation.
