JVC UX-G6 Service Manual

3-19
UX-G6/FS-G6
Electrical parts list (Tuner board) Block No. 04
Item Parts number Parts name AreaRemarks
C 1 NCB21HK-223X C CAPACITOR
C 3 NCB21EK-473X C CAPACITOR
C 4 NCB21HK-103X C CAPACITOR
C 5
Q
EK41CM-106 E.CAPA I.M 10MF 20% 16V
C 6 NCB21HK-102X C CAPACITOR
C 9 NCB21HK-102X C CAPACITOR
C 12 NDU21HJ-100X C CAPACITOR
C 13 NCB21EK-473X C CAPACITOR
C 21 NCB21EK-473X C CAPACITOR
C 30
Q
EK41CM-476 E CAPACITOR 47MF 20% 16V
C 32 NCB21HK-102X C CAPACITOR
C 33
Q
EKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 34 NCS21HJ-150X C CAPACITOR
C 35 NCB21HK-102X C CAPACITOR
C 36
Q
EK41CM-106 E CAPACITOR 10MF 20% 16V
C 37 NCB21EK-473X C CAPACITOR
C 39 NCB21EK-473X C CAPACITOR
C 40 NCB21HK-103X C CAPACITOR
C 41
Q
EKC1HM-104Z E CAPACITOR .10MF 20% 50V
C 42
Q
EK41HM-474 E CAPACITOR .47MF 20% 50V
C 44 NCS21HJ-221X C CAPACITOR
C 45
Q
EKC1HM-335Z E CAPACITOR 3.3MF 20% 50V
C 46 NCB21HK-223X C CAPACITOR
C 47 NCB21HK-103X C CAPACITOR
C 49 NCB21HK-153X C CAPACITOR
C 50 NCB21HK-153X C CAPACITOR
C 51
Q
EKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 52
Q
EKC1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 60
Q
EKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 61 NCS21HJ-120X C CAPACITOR
C 62 NCS21HJ-120X C CAPACITOR
C 63 NCB21EK-473X C CAPACITOR
C 65 NCB21HK-102X C CAPACITOR
C 66 NCS21HJ-151X C CAPACITOR
C 68 NCS21HJ-101X C CAPACITOR
C 69
Q
EKC1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 70 NCB21HK-392X C CAPACITOR
C 71
Q
EKC1HM-335Z E CAPACITOR 3.3MF 20% 50V
C 72 NCB21HK-102X C CAPACITOR
CF 1
Q
AX0419-001Z C FILTER FM IF
CF 2
Q
AX0419-001Z C FILTER FM IF
CF 3
Q
AX0418-001Z C FILTER
CF 4
Q
AX0409-001 CERA LOCK
CN 1
Q
GF1205F1-10 CONNECTOR
D 1 1SS254-T2 SI DIODE
D 2 1SS254-T2 SI DIODE
D 3 1SS254-T2 SI DIODE
D 4 1SS254-T2 SI DIODE
IC 1 TA2057N IC
IC 2 LC72136N IC
J 1
Q
NB0014-001 ANT TERMINAL AM/FM ANT
L 1
QQ
R0796-001 COIL BLOCK MW/LW RF/OSC
L 4
QQ
L231K-221Y INDUCTOR
Q
1 2SC2668/O/-T TRANSISTOR
Q
6 DTA114YKA-X TRANSISTOR
Q
7 2SA1037K/R/-X TRANSISTOR
Q
8 2SA1037K/R/-X TRANSISTOR
R 1 NRSA02J-102X MG RESISTOR
R 2 NRSA02J-820X MG RESISTOR
R 3 NRSA02J-0R0X MG RESISTOR
R 12 NRSA02J-102X MG RESISTOR
R 13 NRSA02J-104X MG RESISTOR
R 20 NRSA02J-331X MG RESISTOR
R 21 NRSA02J-224X MG RESISTOR
R 22 NRSA02J-331X MG RESISTOR
R 23 NRSA02J-270X MG RESISTOR
R 24 NRSA02J-271X MG RESISTOR
R 25 NRSA02J-473X MG RESISTOR
R 27 NRSA02J-223X MG RESISTOR
R 29 NRSA02J-473X MG RESISTOR
R 30 NRSA02J-103X MG RESISTOR
R 31 NRSA02J-103X MG RESISTOR
R 32 NRSA02J-473X MG RESISTOR
R 34 NRSA02J-333X MG RESISTOR
R 35 NRSA02J-333X MG RESISTOR
R 36 NRSA02J-103X MG RESISTOR
R 37 NRSA02J-472X MG RESISTOR
R 38 NRSA02J-392X MG RESISTOR
R 39 NRSA02J-392X MG RESISTOR
R 42 NRSA02J-102X MG RESISTOR
R 43 NRSA02J-102X MG RESISTOR
R 44 NRSA02J-102X MG RESISTOR
R 45 NRSA02J-102X MG RESISTOR
R 46 NRSA02J-473X MG RESISTOR
R 48 NRSA02J-102X MG RESISTOR
R 52 NRSA02J-472X MG RESISTOR
R 54 NRSA02J-472X MG RESISTOR
R 55 NRSA02J-182X MG RESISTOR
R 56 NRSA02J-332X MG RESISTOR
R 57 NRSA02J-102X MG RESISTOR
R 66 NRSA02J-222X MG RESISTOR
R 68 NRSA02J-223X MG RESISTOR
R 69 NRSA02J-103X MG RESISTOR
T 1
QQ
R0793-001 IFT
TU 1
Q
AU0097-001 FRONT END FM TU
X 1
Q
AX0402-001 CRYSTAL
Item Parts number Parts name AreaRemarks
