JVC UX-G6 Service Manual

3-21
UX-G6/FS-G6
Parts list (TD-UXG6 General assembly)
Item
Parts number Parts name
Area
Q'ty
Description
Block No
.
M5MM
1 LV10277-001A FRONT PANEL 1
2 LV31438-002A BUTTON 1 PLATING
3 LV31440-003A BUTTON 1 PLATING
4 LV41325-001A INDICATOR 1
5 LV31458-001A FRONT PLATE 1
6 E406971-222 JVC MARK 1
7 LV41317-002A LENS
(
A
)
1
8 LV41318-002A LENS
(
B
)
1
9 LV41750-001A LABEL 1
10 QYSBSF2608Z T.SCREW 7 FOR SW PWB
11 E75896-002 FELT SPACER 2 FOR FOOT
12 QYSBST3006Z T.SCREW 3 FOR F.PANE+B.CHASSIS
13 LV10274-001A BOTTOM CHASSIS 1
14 --------------- CASSETTE MECHA 1
15 LV20522-001A FITTING 1
16 LV31459-002A FITTING PLATE 1
17 QYSBST3006Z T.SCREW 4 FOR CASS.MECHA
18 QYSBST3006Z T.SCREW 4 CHASSIS.B+PWB
19 LV30064-058A SPACER 1
20 E47227-029 FOOT 2
21 QYSBST3006Z T.SCREW 2 FOR FOOT
22 LV10273-002A/S/ METAL COVER 1
24 QYSDSG3008N T.SCREW 2 M.COVER+B.CHASSIS
25 QYSDSG3008N T.SCREW 4 M.COVER+R.PANEL
26 LV20527-008A REAR PANEL 1 UP
LV20527-007A REAR PANEL 1 U,UB
27 QYSDSG3008N T.SCREW 1
28 QQR1086-001 NOISE FILTER 1
29 E409257-001 GND TERMINAL 1 FOR EARTH
30 QYSDSG3008N T.SCREW 2 FOR PWB BKT
31 WJN0028-001A E-SH C WIRE C-C 1
32 QUQB12-1334AJ FFC WIRE 1
33 QUQB12-1536AJ FFC WIRE 1
34 WJS0016-001A E-FL/RB WIRE 1 13 PIN SYSTEM WIRE
35 LV41786-001A SPACER 1
36 LV41773-001A SHEET 1
