JVC UX-G6 Service Manual

3-23
UX-G6/FS-G6
Grease point
1. CHASSIS
EM-30L
94. MECHA BASE(H)ASSY
CFD-005H
EM-30L
EM-30L
EM-30L
EM-30L
EM-30L
EM-30L
The seat side
is painted.
Right and left
Grease is not available
3. CAM GEAR
The wall side
is painted.
C
D
E
(C,D and E are common.)
EM-30L
EM-30L
EM-30L
EM-30L
EM-30L
The wall side
is painted.
The wall side
is painted.
The wall side
is painted.
EM-30L
The upper surface is painted.
The wall side
is painted.
98. FLYWHEEL(LH)ASSY
97. FLYWHEEL(RH)ASSY
96. CLUTCH ARM ASSY
PSL-12
EM-30L
PSL-12
PSL-12
EM-30L
EM-30L
A
A - A
A
B
B
44. ROTATION HEAD(R/P)
45. HEAD SCREW
40. HEAD PLATE
42. ROTATOR
PSL-12
PSL-12
28. HEAD CHASSIS
EM-30L
