JVC UX-S77 Service Manual

3-14
Micon board
Block No. [0][2][0][0]
J5201 QNS0170-001 HEADPHONE JACK
K5211 QQR0621-001Z COIL
PP300 QZW0112-001 WIRE CLAMP
PP901 QZW0112-001 WIRE CLAMP
PP902 QZW0112-001 WIRE CLAMP
 RY901 QSK0124-001 RELAY
 S9001 QSW0838-001 VOLTAGE SWITCH
S77UJ,
S77UN,
S77US,
S77UW,
S77UX
TH301 QAD0015-103Z THERMISTOR 10k Ω
 Symbol No. Part No. Part Name Description Local
IC202 JCV8011-X IC
IC203 HA17558AF-X IC
IC207 NJM4565M-WE IC
IC520 GP1UM261XK IR DETECT UNIT 38kHz
IC550 NJU6433FG1 LCD DRIVER
IC900 MN101C49GFG IC
IC901 LC75342M-X IC
IC910 GP1FA553TZ OPT TRANSMITTER
IC999 BR24L01AF-W-X IC
Q2070 2SD601A/R/-X TRANSISTOR
Q2071 2SD601A/R/-X TRANSISTOR
Q2170 2SD601A/R/-X TRANSISTOR
Q2171 2SD601A/R/-X TRANSISTOR
Q2250 2SD601A/R/-X TRANSISTOR
Q2251 UN2111-X TRANSISTOR
Q2270 UN2111-X TRANSISTOR
Q2900 2SC2412K/R/-X TRANSISTOR
Q7035 UN2215-X TRANSISTOR
Q7036 UN2215-X TRANSISTOR
Q7074 UN2211-X TRANSISTOR
Q7300 2SD601A/R/-X TRANSISTOR
Q7301 UN2215-X TRANSISTOR
Q7400 KTC3199/GL/-T TRANSISTOR
Q7401 KTC3199/GL/-T TRANSISTOR
Q7402 KTC3199/GL/-T TRANSISTOR
Q7600 2SB709A/R/-X TRANSISTOR
Q7601 UN2211-X TRANSISTOR
Q7700 UN2211-X TRANSISTOR
Q7701 UN2211-X TRANSISTOR
Q7710 UN2211-X TRANSISTOR
Q7711 UN2211-X TRANSISTOR
Q7940 2SD601A/R/-X TRANSISTOR
Q7941 2SD601A/R/-X TRANSISTOR
Q7950 UN2115-X D.TRANSISTOR
D2100 1SS119-041-T2 DIODE
D2101 1SS119-041-T2 DIODE
D2321 MTZJ4.7B-T2 Z DIODE
D2770 1SS119-041-T2 DIODE
D2900 1N4003S-T5 SI DIODE
D2901 1SS119-041-T2 DIODE
D5260 SPR-39MVWF LED RED-GREEN
D5460 SELU1E10WXM-P LED
D5461 SELU1E10WXM-P LED
D5462 SELU1E10WXM-P LED
D7075 1SS355-X SI DIODE
D7206 MTZJ5.6C-T2 Z DIODE
D7209 MTZJ5.6C-T2 Z DIODE
D7300 1SS119-041-T2 DIODE
D7301 1SS119-041-T2 DIODE
D7302 MTZJ5.1C-T2 Z DIODE
D7303 1SS119-041-T2 DIODE
D7304 1SS119-041-T2 DIODE
D7600 1SS119-041-T2 DIODE
D7802 MTZJ6.2C-T2 Z DIODE
 Symbol No. Part No. Part Name Description Local
C2004 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2005 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2007 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2008 QTE1H28-106Z E CAPACITOR 10uF 50V
C2009 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2010 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2011 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2013 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C2019 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C2051 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2053 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2061 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C2062 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C2071 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2072 NDC31HJ-151X C CAPACITOR 150pF 50V J
C2073 NCS31HJ-101X C CAPACITOR 100pF 50V J
C2074 NCB31HK-331X C CAPACITOR 330pF 50V K
C2075 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2100 NCB31HK-221X C CAPACITOR 220pF 50V K
C2101 NCB31HK-221X C CAPACITOR 220pF 50V K
C2102 NCB31HK-102X C CAPACITOR 1000pF 50V K
C2104 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2105 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2106 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2107 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2108 QTE1H28-106Z E CAPACITOR 10uF 50V
C2109 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2110 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2111 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2112 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2113 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C2119 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C2151 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2153 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2161 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C2162 QFLC1HJ-123Z M CAPACITOR 0.012uF 50V J
C2171 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2172 NDC31HJ-151X C CAPACITOR 150pF 50V J
C2173 NCS31HJ-101X C CAPACITOR 100pF 50V J
C2174 NCB31HK-331X C CAPACITOR 330pF 50V K
C2175 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2221 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2222 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2223 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2240 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2241 QETN1HM-105Z E CAPACITOR 1uF 50V M
C2242 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2250 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2251 QETN1EM-476Z E CAPACITOR 47uF 25V M
C2252 QFLC1HJ-273Z M CAPACITOR 0.027uF 50V J
C2253 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2254 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2255 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2256 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2257 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2258 QETN1EM-106Z E CAPACITOR 10uF 25V M
C2259 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C2261 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C2262 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C2270 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2271 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2272 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C2301 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C2302 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2312 QETN1CM-226Z E CAPACITOR 22uF 16V M
C2321 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2322 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2361 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C2362 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C2702 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C2900 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3211 QFLC1HJ-823Z M CAPACITOR 0.082uF 50V J
C5104 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5105 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5200 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5201 QERF1CM-226Z E CAPACITOR 22uF 16V M
 Symbol No. Part No. Part Name Description Local
