JVC UX-S77 Service Manual

3-17
Video board
Block No. [0][3][0][0]
Loading board
Block No. [0][4][0][0]
DVD servo board
Block No. [0][5][0][0]
 Symbol No. Part No. Part Name Description Local
IC451 MM1623XF-X IC
C4501 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4502 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4503 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4504 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4505 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4506 QCBB1HK-181Y C CAPACITOR 180pF 50V K
C4550 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4551 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C4552 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C4553 QETN1HM-105Z E CAPACITOR 1uF 50V M
C4554 QETN1HM-105Z E CAPACITOR 1uF 50V M
C4555 QETN1HM-105Z E CAPACITOR 1uF 50V M
C4601 QETN1AM-477Z E CAPACITOR 470uF 10V M
C4602 QETN1AM-477Z E CAPACITOR 470uF 10V M
C4603 QETN1AM-477Z E CAPACITOR 470uF 10V M
C4604 QETN1AM-477Z E CAPACITOR 470uF 10V M
C4605 QETN1HM-105Z E CAPACITOR 1uF 50V M
C4606 QETN1AM-477Z E CAPACITOR 470uF 10V M
C4650 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4651 QETN1CM-226Z E CAPACITOR 22uF 16V M
R4501 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4502 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4503 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4504 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4505 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4506 QRE141J-750Y C RESISTOR 75 Ω 1/4W J
R4541 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R4542 QRE141J-302Y C RESISTOR 3k Ω 1/4W J
R4543 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R4544 QRE141J-302Y C RESISTOR 3k Ω 1/4W J
R4545 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R4546 QRE141J-911Y C RESISTOR 910 Ω 1/4W J
R4547 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R4548 QRE141J-911Y C RESISTOR 910 Ω 1/4W J
R4549 QRE141J-201Y C RESISTOR 200 Ω 1/4W J
R4550 QRE141J-302Y C RESISTOR 3k Ω 1/4W J
CN451 QGB2024J1-11S CONNECTOR B-B (1-11)
CN452 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
J4501 QNN0579-001 PIN JACK
J4502 QNZ0430-001 AV JACK
VY451 VYH7653-003 IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0003AA-H IC
IC302 LM1117MP-ADJ-X IC
IC451 MN101C61GNC IC(MCU)
IC452 BR93L56RFV-W-X IC
IC453 S-80827CNNB-W IC
IC505 K4S641632F-TC75 IC(DIGITAL)
IC509 AT49LV1614T90TC IC (FLASH)
IC701 AK4384VT-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
D101 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C208 NCB31HK-561X C CAPACITOR 560pF 50V K
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C253 NCB31HK-561X C CAPACITOR 560pF 50V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
