JVC UX-S77 Service Manual

3-20
R315 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R327 QRE141J-474Y C RESISTOR 470k Ω 1/4W J
R335 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R336 QRE141J-223Y C RESISTOR 22k Ω 1/4W J
R337 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R338 QRE141J-392Y C RESISTOR 3.9k
Ω 1/4W J
R339 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R340 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R341 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R342 QRE141J-243Y C RESISTOR 24k Ω 1/4W J
R343 QRE141J-183Y C RESISTOR 18k Ω 1/4W J
R344 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R345 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R346 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R347 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
 R353 QRZ9005-100X FUSI RESISTOR 10 Ω
R372 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R375 QRE141J-151Y C RESISTOR 150 Ω 1/4W J
R376 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
VR31 QVP0008-203Z TRIM RESISTOR 20k Ω
L301 QQR1118-002 OSC COIL(BIAS)
L303 QQL244K-100Z COIL 10uH K
CN31 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN32 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN33 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN34 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
H32 GV40397-002A IC HOLDER
 Symbol No. Part No. Part Name Description Local
