JVC XV-THA85 Service Manual

3-12
Electrical parts list
Main board
Block No. [0][1][0][0]
 Symbol No. Part No. Part Name Description Local
IC411 MM1233XF-X IC
IC431 LA73054-X IC
IC471 MN101C49GKS1 IC(MCU)
IC472 BD4740G-W IC
IC491 KIA7805API IC
IC601 HA17558AF-X IC
 IC901 STR-G6651 IC
IC951 PQ05RD21 IC
IC953 KIA7805API IC
Q581 KRC102S-X DIGI TRANSISTOR
Q951 2SC3576-JVC-T TRANSISTOR
Q952 KRA104S-X DIGI TRANSISTOR
Q953 KTA1267/YG/-T TRANSISTOR
Q954 SI2305DS-X TRANSISTOR
Q955 KRC103S-X DIGITAL TR
Q958 KTA1271/OY/-T TRANSISTOR
Q959 2SD601A/QR/-X TRANSISTOR
Q960 2SB709A/QR/-X TRANSISTOR
Q961 KTA1271/OY/-T TRANSISTOR
Q964 KTA1046/Y/ TRANSISTOR
Q965 2SD601A/QR/-X TRANSISTOR
Q991 2SD601A/QR/-X TRANSISTOR
Q4091 KTA1271/OY/-T TRANSISTOR
Q4092 2SD601A/QR/-X TRANSISTOR
Q4701 KRC111S-X TRANSISTOR
Q4702 KRC107S-X DIGI TRANSISTOR
Q4703 KRC102S-X DIGI TRANSISTOR
Q4801 2SB709A/QR/-X TRANSISTOR
Q4802 KRC102S-X DIGI TRANSISTOR
Q4811 KRA102S-X DIGI TRANSISTOR
Q4812 KRC102S-X DIGI TRANSISTOR
Q4821 KRC102S-X DIGI TRANSISTOR
Q4831 KRC102S-X DIGI TRANSISTOR
Q4921 KTC3203/OY/-T TRANSISTOR
Q4931 KTA1271/OY/-T TRANSISTOR
D581 SLR-342VC-T LED I.M
 D901 S1WB/A/60-4101 BRIDGE DIODE
D902 ERA18-04-T1 FR DIODE
D903 ERA18-04-T1 FR DIODE
D904 ERA18-04-T1 FR DIODE
D908 ERA18-04-T1 FR DIODE
D910 ERA18-04-T1 FR DIODE
D911 ERA18-04-T1 FR DIODE
D950 MTZJ36C-T2 Z DIODE
D951 ERA18-04-T1 FR DIODE
D951 or AU02-T1 FR DIODE
D952 ERA18-04-T1 FR DIODE
D952 or AU02-T1 FR DIODE
 D953 FMB-24 FUSEIODE
 D954 EU2YX-LFH6K FR DIODE
 D956 EU2YX-LFH6K FR DIODE
 D957 EU2YX-LFH6K FR DIODE
D958 MTZJ9.1A-T2 Z DIODE
D960 MTZJ3.6B-T2 Z DIODE
D961 1SS133-T2 DIODE
D962 1SS133-T2 DIODE
D970 1SS133-T2 DIODE
D975 1SS133-T2 DIODE
D991 MTZJ5.1B-T2 Z DIODE
D4091 1SS133-T2 DIODE
D4092 MTZJ6.8A-T2 Z DIODE
D4701 1SS133-T2 DIODE
D4702 1SS133-T2 DIODE
D4703 MTZJ4.7B-T2 Z DIODE
D4704 1SS355-X SI DIODE
D4705 1SS355-X SI DIODE
D4811 1SS133-T2 DIODE
D4831 1SS133-T2 DIODE
D4832 1SS133-T2 DIODE
D4833 1SS133-T2 DIODE
D4834 1SS133-T2 DIODE
D4835 MTZJ6.8A-T2 Z DIODE
D4841 1SS133-T2 DIODE
D4891 MTZJ6.8A-T2 Z DIODE
D4921 MTZJ8.2C-T2 Z DIODE
D4922 1SS133-T2 DIODE
D4931 MTZJ8.2C-T2 Z DIODE
D4932 1SS133-T2 DIODE
 PC901 PC123Y22FZ PHOTO COUPLER
 PC902 PC123Y22FZ PHOTO COUPLER
 C902 QFZ9075-683 MPP CAPACITOR 0.068uF AC275V M
 C904 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C905 QCZ9079-102 C CAPACITOR 1000pF AC250V M
 C907 QEZ0577-826 E CAPACITOR 82uF
C908 QCZ0136-332Z C CAPACITOR 3300pF 1kV K
C909 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C910 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C913 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C914 QEZ0532-396Z E CAPACITOR 39uF 25V M
C915 QCBB1HK-471Y C CAPACITOR 470pF 50V K
 C916 QCZ9079-222 C CAPACITOR 2200pF AC250V M
C917 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C918 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C951 NCS31HJ-101X C CAPACITOR 100pF 50V J
C952 QCZ0136-101Z C CAPACITOR 100pF 1kV K
C953 NCS31HJ-101X C CAPACITOR 100pF 50V J
C954 NCS31HJ-101X C CAPACITOR 100pF 50V J
C956 NCS31HJ-101X C CAPACITOR 100pF 50V J
C957 NCS31HJ-101X C CAPACITOR 100pF 50V J
C960 QEZ0529-826Z E CAPACITOR 82uF 10V M
C961 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C962 QETN1HM-226Z E CAPACITOR 22uF 50V M
C963 QEZ0533-396Z E CAPACITOR 39uF 50V M
C964 QETN1HM-226Z E CAPACITOR 22uF 50V M
C965 QTMN1AM-108Z E CAPACITOR 1000uF 10V M
C966 QETN1AM-477Z E CAPACITOR 470uF 10V M
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C969 QETN1AM-227Z E CAPACITOR 220uF 10V M
C970 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C973 QETN1CM-107Z E CAPACITOR 100uF 16V M
C976 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C977 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C978 QETN1CM-107Z E CAPACITOR 100uF 16V M
C979 QEZ0530-827 E CAPACITOR 820uF 16V M
C980 QETN1HM-106Z E CAPACITOR 10uF 50V M
C981 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C982 QEZ0531-567 E CAPACITOR 560uF 25V M
C983 QETN1HM-106Z E CAPACITOR 10uF 50V M
C984 QETN1CM-227Z E CAPACITOR 220uF 16V M
C985 QETN1EM-107Z E CAPACITOR 100uF 25V M
C986 QETN1EM-107Z E CAPACITOR 100uF 25V M
C987 QEZ0532-187Z E CAPACITOR 180uF 25V M
C989 QETN1CM-107Z E CAPACITOR 100uF 16V M
C992 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C993 NCS31HJ-101X C CAPACITOR 100pF 50V J
C994 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C997 QETN1CM-227Z E CAPACITOR 220uF 16V M
C4001 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C4002 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C4091 QETN1HM-106Z E CAPACITOR 10uF 50V M
C4092 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4101 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4102 NCS31HJ-470X C CAPACITOR 47pF 50V J
C4111 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C4112 NCS31HJ-470X C CAPACITOR 47pF 50V J
C4121 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4122 NCS31HJ-470X C CAPACITOR 47pF 50V J
C4171 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4172 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C4191 QETN1VM-476Z E CAPACITOR 47uF 35V M
C4192 NCB31HK-103X C CAPACITOR 0.01uF 50V K
 Symbol No. Part No. Part Name Description Local
