3-14
Front board
Block No. [0][2][0][0]
DSP board
Block No. [0][3][0][0]
R4831 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R4832 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R4833 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R4834 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R4835 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R4841 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R4842 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R4861 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4862 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4863 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4864 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4865 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4866 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4867 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4868 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4871 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4872 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4873 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4874 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R4881 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4882 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4883 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4884 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4885 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R4891 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4892 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R4921 QRZ9005-100X F RES I/M 10
Ω
R4922 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R4931 QRZ9005-100X F RES I/M 10
Ω
R4932 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R6101 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6102 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6103 NRSA63J-154X MG RESISTOR 150k
Ω
1/16W J
R6104 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6105 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R6106 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
R6107 NRSA63J-390X MG RESISTOR 39
Ω
1/16W J
R6301 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6901 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R6902 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R6903 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
R6904 QRE141J-271Y C RESISTOR 270
Ω
1/4W J
L901 QQR1105-001 LINE FILTER
L951 QQL244K-R22Z COIL 0.22uH K
L952 QQL44BK-220Z COIL 22uH K
L955 QQL26AK-220Z COIL 22uH K
L957 QQL244K-100Z COIL 10uH K
L959 QQL244K-100Z COIL 10uH K
L4391 QQL25CK-221Z COIL 220uH K
T901 QQS0097-001 SW TRANSF
CN405 QGB2027M9-26 CONNECTOR B-B (1-26)
CN406 QGB2027M9-26 CONNECTOR B-B (1-26)
CN407 QGB1216J1-14S CONNECTOR B-B (1-14)
CN408 QGA2001C1-03 CONNECTOR W-B (1-3)
CN410 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN411 QGF1016C1-31 CONNECTOR FFC/FPC (1-31)
CN412 QGA2001C1-06 CONNECTOR W-B (1-6)
CN901 QGA2001C1-12 CONNECTOR W-B (1-12)
CN902 QGA2501C1-10 CONNECTOR W-B (1-10)
CP471 ICP-N5-T IC PROTECTOR 250mA
CP951 ICP-N10-T IC PROTECTOR 400mA
CP952 ICP-N5-T IC PROTECTOR 250mA
EP401 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP902 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
HS491 LE40505-001A HEAT SINK
HS901 E70306-002 HEAT SINK
HS964 LE40505-001A HEAT SINK
J4402 QNN0572-001 PIN JACK
J4411 QNN0570-001 PIN JACK
J4891 QNS0089-001 3.5 JACK
P901 QNC0081-001 AC INLET
PP901 QZW0038-001 WIRE CLAMP
PP902 QZW0038-001 WIRE CLAMP
Symbol No.
Part No. Part Name Description Local
S551 QSW0683-001Z PUSH SW
S552 QSW0683-001Z PUSH SW
S553 QSW0683-001Z PUSH SW
S561 QSW0683-001Z PUSH SW
S562 QSW0683-001Z PUSH SW
S563 QSW0683-001Z PUSH SW
S564 QSW0683-001Z PUSH SW
S565 QSW0683-001Z PUSH SW
S581 QSW0683-001Z PUSH SW
S4401 QSW0454-001 SW
X4701 QAX0246-001Z C RESONATOR 8.00MHz
Symbol No.
Part No. Part Name Description Local
IC501 MN101C35DKW IC(MPU)
IC502 GP1UM271XK IR DETECT UNIT 38kHz
Q501 KRC102S-X DIGI TRANSISTOR
Q502 KRC102S-X DIGI TRANSISTOR
Q511 KRC102M-T DIGI TRANSISTOR
Q521 KRC111M-T TRANSISTOR
D511 SELU2E10C-P LED
C501 NCB31HK-471X C CAPACITOR 470pF 50V K
C502 NCB31HK-471X C CAPACITOR 470pF 50V K
C503 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C504 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C505 QEKC0JM-107Z E CAPACITOR 100uF 6.3V M
C507 NCB21CK-105X C CAPACITOR 1uF 16V K
C511 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C512 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C571 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C572 NCB31CK-223X C CAPACITOR 0.022uF 16V K
C573 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C574 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R501 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R502 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R503 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R504 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R511 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R521 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R571 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
CN501 QGB1216K1-14S CONNECTOR B-B (1-14)
CN502 QGA2001F1-02 CONNECTOR W-B (1-2)
DI501 QLF0119-002 FL TUBE
J571 QNS0170-001 HEADPHONE JACK
K571 NQR0007-002X FERRITE BEADS
K572 NQR0007-002X FERRITE BEADS
K573 NQR0007-002X FERRITE BEADS
K574 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
S571 QSW0683-001Z PUSH SW
X501 QAX0246-001Z C RESONATOR 8.00MHz
Symbol No.
Part No. Part Name Description Local
IC151 BU4066BCF-X IC
IC153 M62446AFP-X IC
IC158 NJM4565M-WE IC
IC159 NJM4565M-WE IC
IC160 NJM4565M-WE IC
IC401 AK4527BVQP IC
Symbol No.
Part No. Part Name Description Local
