JVC XV-THA85 Service Manual

3-24
DVD loading switch board
Block No. [0][8][0][0]
R565 NRVA63D-622X CMF RESISTOR 6.2k Ω 1/16W D
R566 NRVA63D-132X CMF RESISTOR 1.3k Ω 1/16W D
R570 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R573 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R574 NRSA63J-162X MG RESISTOR 1.6k Ω 1/16W J
R575 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R576 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R578 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R579 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R580 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R583 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R584 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R608 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R655 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R738 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R739 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R740 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R991 NRSA63J-220X MG RESISTOR 22 Ω 1/16W J
L501 NQL044K-100X COIL 10uH K
CN101 QGF0522F1-30W CONNECTOR FFC/FPC (1-30)
CN201 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN202 QGF1016F2-06W CONNECTOR FFC/FPC (1-6)
CN502 QGB2027L1-26X CONNECTOR B-B (1-26)
CN503 QGB2027L1-26X CONNECTOR B-B (1-26)
IC509 SST39VF160-9DD IC
K101 NQR0007-002X FERRITE BEADS
K301 NQR0007-002X FERRITE BEADS
K302 NQR0007-002X FERRITE BEADS
K303 NQR0007-002X FERRITE BEADS
K304 NQR0007-002X FERRITE BEADS
K401 NQR0007-002X FERRITE BEADS
K501 NQR0007-002X FERRITE BEADS
K504 NQR0007-002X FERRITE BEADS
K505 NQR0007-002X FERRITE BEADS
K507 NQR0007-002X FERRITE BEADS
K508 NQR0007-002X FERRITE BEADS
K509 NQR0007-002X FERRITE BEADS
K510 NQR0007-002X FERRITE BEADS
K513 NQR0007-002X FERRITE BEADS
K515 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K518 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K519 NQR0007-002X FERRITE BEADS
K520 NQR0007-002X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K557 NQR0129-002X FERRITE BEADS
K558 NQR0129-002X FERRITE BEADS
K559 NQR0129-002X FERRITE BEADS
K560 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K561 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K562 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K563 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K564 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K565 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K566 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K567 NQR0007-002X FERRITE BEADS
K568 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K569 NQR0007-002X FERRITE BEADS
K570 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K571 NQR0007-002X FERRITE BEADS
K572 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K573 NQR0007-002X FERRITE BEADS
K574 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K575 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K576 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K577 NQR0007-002X FERRITE BEADS
K578 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K579 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K582 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K586 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
X301 NAX0542-001X C RESONATOR 16.93MHz
X401 NAX0543-001X C RESONATOR 13.50MHz
X571 NAX0513-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-06 CONNECTOR FFC/FPC (1-6)
S1 QSW0910-002 SWITCH
S2 QSW0910-002 SWITCH
