JVC XV-THD5 User Manual

SCHEMATIC DIAGRAMS
TH-D5B,TH-D5E,TH-D5EN
TH-D5EV
Contents
Block diagrams
Standard schematic diagrams
Printed circuit boards
2-1
2-2
2-14 to 18
CD-ROM No.SML200707
DVD DIGITAL CINEMA SYSTEM
No.MB618SCH
2007/7
COPYRIGHT 2007 Victor Company of Japan, Limited.
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
XV-THD5
SP-THD5W
SP-THD5S
SP-THD5C
SP-THD5F

JVC XV-THD5 Specifications

General

Brand	JVC
Model	XV-THD5
Category	Home Theater System
Language	English
