JVL Echo - Page 30

Copyright © 2011 JVL Labs All Rights Reserved
Appendix A
30
Depress both latches
to remove the Cover
Depress both latches
to remove the Cover
Fig. 5
CT09-122 CPU
GAMEBOARD ASSEMBLY
Hex Nut #8-32
Fig. 6
