Appendix A
35
Fig. 14
Inner Fans: DC12V-50 x 50 x 15 mm
P/N: KDE1205PHV2 MS.AF.GN
Machine Screw #4-40 x 16”, Philips Head, 4 Places
Air Flow Direction
