Appendix A
39
Fig. 20
Fig. 21
3 6Touch Screen cable
Hex Lock Nut #8-32 Clamp
LVDS cable
NOTE: Touch screen USB cable is labeled HNS-CT09-716 and can be connected to any USB slot on
the Game Box.
