Appendix A
54
Fig. 47
Fig. 48
2x Machine Screw
#8-32 x 3/8” LNG.,
Pan Head Philips
2x Machine Screw
#8-32 x 1” 1/4” LNG.,
Pan Head Philips
CT09-101
Monitor Assy
2x Machine Screw
#8-32 x 1/4” LNG.,
Phill Pan Screw
2x Flat Washer #8
