14
10. TEChNICAL SPECIfICATIoNS
Notes for data
1. With dedicated preset;
2. Measured @4 mt then scaled @1 mt;
3. Measured with musical signal
New materials and design are introduced into existing products without previous notice.
Present systems may differ in some respects from those presented in this catalogue.
ACOUSTICS
Power handling 1200 W
Max power 1800 W
Frequency range 90 Hz – 20 kHz (- 3dB)
(1)
Impedance 8 Ω / 32 Ω (selectable)
SPL 1W/1mt 102 dB
(2)
Maximum SPL 132 dB (cont.) – 138 dB (peak)
(3)
COVERAGE
Horizontal 90°
Vertical 7° / 30° (selectable)
CROSSOVER
Type External crossover required
Frequency
High pass @ 90 Hz, 24 dB/oct suggested
minimum
TRANSDUCERS
Full range 8 x 4” Neodymium magnet cone drivers
SELECTION SWITCHES
Impedance 8 Ω / 32 Ω
Coverage Spot / Flood
POWER AUDIO INPUT/OUTPUT
Connector 2 x 4-pin Speakon
Wiring 1+ 1- (signal IN & LINK); 2+ 2- (through)
RECOMMENDED AMPLIFIERS
Type KA84, KMT
CERTIFICATION
IP 54
PHYSICAL
Dimensions
11.3 x 100 x 13.2 cm
(4.45” x 39.4” x 5.2”)
Weight 14.9 kg (32.8 lbs)
The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may
appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
