K-array Redline KL18ma - Technical Data

Technicaldata
Acoustics
Powerhandling
Maxpower
Impedance
Operatingfrequencyrange
Frequencyrange
SPL 1W/1mt
MaximumSPL
Crossover
Type
Frequency
Transducers
Lowfrequency
Highfrequency
AudioInput
Connectors
Wiring
AudiopoweredOutput
Connector
Wiring
RemotecontrolInput
Connectors
PowerInput
Connectors
Amplifiers
Type
Subwooferpower
Satellitepoweroutput
Protections
ACpower
Operatingrange
Maxcontinuosandburstcurrent
Physical
Measures
Weight
800(sub)+500(sat)w
1
1200(sub)+1200(sat)w
8 (sub)+8 (sat)
30Hz-19KHz+/-3dB(presetrelating)
35Hz-19KHz+/-3dB(presetrelating)
97dB(sub)101dB(sat)
127dBcontinuos-133dBpeak
DSP controlledpresetrelating
150Hzminimum(presetrelating)
1x18"Neodymiumspeakerswith3"voicecoil
32x2"Neodymiumspeakerswith0,75"voicecoil
male+femaleparallel3polesbalancedXLR
=ground/ =hot/ =cold
FemaleSpeakon
=CH1+/ =CH1-/ =N.C./ =N.C.
1xfemale8polesRJ45
2xPowerConIN/OUT
1modulesclassD-DSP controlled
1000Watt
1000Watt
Dynamiclimiter,overcurrent,overtemp,shortcircuits
Standard210 -240Vac50Hz(standard)
Standard6A(>10sec)-12A (<1sec)
46.5x46.5x58.5cm(KL18ma)5.5x7x200cm(KR200)
20Kg(KL18ma)9Kg(KR200)
2
3
4
5
6
7
8
8
W W
Pin1 Pin2 Pin3
Pin1+ Pin1- Pin2+ Pin2-
Optional100-120Vac60Hz(optional)
Optional10A(>10sec)-20A (<1sec)
Notesfordata
1. Power handling is measured following AES standard conditions: transducers driven continuously for two hours with a band-limited noise signal having 6 dB of crest factor.
2. Max power is the maximum RMS applicable power for a musical signal, the referement signal is the one proposed by EIAJ standard.
3. Recommended maximum operating frequency range. Response depends on loading conditions and room acoustics.
4. Free field measured with 1/3 octave frequency resolution at 2 mt.
5. Measured@4 mt then scaled@1 mt.
6. Measured with audio source @1 mt.
7. This is the frequency in which the transducers produce the same sound pressure level (measured@2 mt).
8. Amplifier wattage rating is based on the maximum unclipped burst sine wave RMS voltage that the amplifier will produce into the nominal load impedance .
