2.3.2 Installation ways of WVC Modem which the distance is more than
15M
Ifyoursystemhasmorethanonegroupofmicroinvertersandtheinstallationdistanceisfar,weneedtochooseRS485
interface.WeneedaddaconcentratorforRS232serialportbetweenWVCModemandacomputer.Thefunctionof
concentratoristomakeonecomputercanconnecttoseveralWV
CModems.Belowisconcentratorofeightserialports,
justasexamplesillustrate
：


WVCModemsinstallationdetailsasfollows:
1.ConnectWVCModemwithserialportlineconnectorthoughRS485serialportline;
2.ConnectRS232serialportlineofWVCModemwithPC;
3.ConnectandturnonallWVCModems;
4.WVCModemsinstallationcomplete;

2.4EquipmentinitializationandInstructions
KaiDengWVCModemwillstarttoinitializeautomaticallyafewsecondslaterafterpoweron,andindicatorlightwillbe
flashingforabout1minuteuntilinstallationcomplete.
WVCModemwillautomaticallycompletepartofinstructionsand
KaiDengMonitoringSystemwillmanuallyorautomaticallycompletetherestinstructions.(ReferringtoKaiDengMonitoring
SystemInstructions)
ThesequenceofdevicesstartandoperationisthemostimportantinKaiDengGenerationSystem,anddetailsofthe
sequencepleaserefertosection2.4ofthemanual.

2.5Equipmentsoperationsequenceinstructions

ThedevicesofthenewcommunicationalPVgeneratesystemcouldworkingoodconditiontoachievethebest.Inorderto
haveKaiDengcommunicationalPVgeneratesystemoperateandworkfluently,pleasepayattentiontosystemoperation
