Kaiser Baas KBA15007 - DRONE COMPONENTS AND MAINTENANCE

16
EN
GIMBAL DIAL
The left side of the Transmitter features a Gimbal Control Dial.
[Important] The Gimbal is an optional accessory, purchased separately
(KBA15008)
The Gimbal Dial only functions when a Gimbal is attached and connected
to the Drone. See Gimbal User Guide.
When connected, the Gimbal Dial allows the Pilot to control the tilt of the
attached camera.
DELTA DRONE
GPS QUADCOPTER
1. START/TAKE OFF
2. GPS HOVER MODE
3. SMART ORIENTATION MODE
GIMBAL
HOLD HERE
TO LOCK GPS
DELTA DRONE
GPS QUADCOPTER
1. START/TAKE OFF
2. GPS HOVER MODE
3. SMART ORIENTATION MODE
GIMBAL
HOLD HERE
TO LOCK GPS
