DRONE SPECIFICATIONS
Delta Drone Diagram:
Delta Drone Lighting
The Delta Drone features LED lights under each arm. These are the best
way of telling which way the Delta Drone is oriented.
SYSTEM STATUS LED FLASHING
System self-checking (No GPS)
Finish Self-checking
Gyro calibration
Compass problem
GPS Lock and Take-o Location
recorded
The rear of the Drone is fitted with Green LED lights and the front of the
Drone is fitted with Red LED lights.
The LED lights also function as a Drone Health Warning System. You
should always monitor the LED lights on the Delta Drone because they are
the primary warning indicator if a problem occurs or if the Low Voltage
Alert (LVA) has been triggered.
DELTA DRONE
GPS QUADCOPTER
A
B
D
E
F
C
A
Motor
D
Rotor Blade
B
Landing Gear
E
Gimbal Mount
C
LED Status Display
F LED Lights
