KAM KCD 1000 CDG - Control Unit Button and Dial Functions

MAIN FEATURES
CONTROL UNIT
(1) SHUTTLE (Shuttle Dial)
(2) OPEN/CLOSE
(Open/Close Button)
(3) TIME (Time Button)
(4) LCD (Liquid Crystal Display)
(5) SGL (Single Button)
(6) PROGRAM (Program Button)
(7) PROGRAM Indicator
(8) LOOP Indicator
(9) LOOP (Loop Button)
(10)PITCH Indicator
(11)JOG (Jog Dial)
(12)B. SKIP
(13)CUE Indicator
(14)CUE (Cue Button)
(15)+10 (Track +10 Button)
(16)PLAY/PAUSE
/
(Play/Pause Button)
(17)PLAY Indicator
(18)F. SKIP
(19)PITCH - (Pitch Bend - Button)
(20)PITCH +(Pitch Bend + Button)
(21)PITCH (Pitch Button)
(22)Pitch Slider
(23)CONTROL START SOCKETS
(24)CONTROL CONNECTOR
LCD
25
26 27 28 29 30 31 32
(25) ~(28)TRACK, MINUTE, SECOND and FRAME
Displays
(29) TIME BAR Indicators
(30) CONTINUE Indicator
(31) REMAIN Indicator
(32) PITCH Displays
