2. PRODUCT OVERVIEW
2.1 Drive System and Applications
This product is a vertical water-cooled small type muti-purpose diesel engine.
The power is transmitted downward from the engine to make the driven
machine structure simple. Since the engine requires a small mounting area,
compact driven machine can be designed.
Powerful and long-lasting torque characteristics are available for efficiency
improvement.
The engine is economical as it consumes extremely little fuel and lube oil.
The durability and reliability are increased by the forced water cooling (radiator)
and forced lubrication system.
The combustion performance is high and the engine is clean with little toxic
exhaust constituents. It is ecology oriented with significantly less vibration and
noise.
The structure facilitates operation and maintenance.
We are sure that you will be satisfied with the above feature.
The main engine specifications are standardized for multi-purpose application.
Options (fuel tank, remote controller, instruments, alarms, etc.) are provided to
meet various operating conditions.
Since installation and fitting of the engine require special knowledge and skill,
always consult with your dealer or KAMA distributor.
--
3. Replacing air cleaner element
Damaged air cleaner element admits suspended matters in the open air into the
combustion chamber to cause early engine wear and shortening of the engine
service life. The air cleaner element significantly clogged with dust also reduces
the engine output.
Replace the air cleaner element will a new one at regular intervals.
See section 5.3.2 3
5.3.4 Check every 400 hours of operation
1. Replacing fuel filter
Replace the filter at regular intervals before it is clogged with dust to adversely
affect the fuel flow.
(1) Close the cock of the fuel tank.
(2) Loosen the hose clips on the fuel filter inlet and outlet joints to remove the
fuel hose.
(3) Draw out the element assembly and remove it from the support.
(4) Press in a new fuel filter into the support until it is fixed in position.
(5) Connect the hoses to the inlet and outlet joints. Fix them with hose clips.
(6) After assembling, bleed air from the fuel system.
See section 3.2.2.
--
Clip
Fuel filter support
To Next Page
